REGAL REXNORD A177 Speed Reducer 25:1

Product Description

The REGAL REXNORD A177 is a reliable inline speed reducer with a gear ratio of 25:1. This unit provides a hollow shaft input and shaft output, featuring a planetary-spur gear mechanism from the NT23 series.

• Features a 25:1 nominal gear ratio for speed reduction.
• Designed with flange mounting for secure installation.
• Constructed with anodized aluminum housing.

Product Highlights

This speed reducer is ideal for applications requiring reliable speed reduction and control.

Product Information

Standard Information

• Brand: Regal Rexnord
• MPN: A177

Technical Specifications

• Reducer Type: Inline
• Gear Ratio: 25:1
• Input Type: Hollow Shaft
• Output Type: Shaft
• Gear Type: Planetary-Spur
• Manufacturer Series: NT23
• Housing Material: Anodized Aluminum
• Mounting Method: Flange Mounted
• Output Shaft Diameter: 0.375 inches
• Output Shaft Length: 0.85 inches
• Overall Height: 2.4 inches
• Overall Length: 4.83 inches
• Overall Width: 2.4 inches
• Bolt Hole Diameter: 0.195 inches
• Maximum Output RPM: 70
