Product Description
The REGAL BELOIT H995 Century motor is a 5.0 HP motor designed for pool and spa applications. This 3-Phase motor operates at 208-230/460V and 3450 RPM. It features open drip proof technology for water damage protection and Class B Insulation to prevent overheating. The motor has a 56Y frame with a 5/8 inch threaded shaft.
- 56Y Frame 5/8 Inch Threaded Shaft
- Operates at 3450 RPM, 208-230/460V, 13.4/6.7A
- Open drip proof technology for water damage protection
Product Highlights
This 5.0 HP Century motor is suitable for Pentair/Pac Fab replacement with a square flange and no base. It has ball bearings for long lasting lifespan.
Product Information
Standard Information
-
Brand: REGAL BELOIT
-
Manufacturer Part Number: H995
-
Country of Origin: United States
Technical Specifications
-
Voltage: 208-230/460V Three Phase
-
Manufacturer: Century Motors
-
Horsepower: 5 HP
-
Product Category: Pump Motors
-
Frame: 56Y
-
Phase: 3-Phase
-
Mount: Threaded
-
Ambient Temperature: 40 deg C
-
Bearing Type: Ball
-
Brand: Regal Beloit
-
Diameter: 6-1/2 Inch
-
Duty Cycle: Continuous
-
Efficiency Group: Standard
-
Enclosure Design: Open Dripproof
-
Finish Color: Black
-
Flange Material: Aluminum
-
Flange Type: Square
-
Frequency Rating: 60 Hz
-
Full Load Amps: 13.4-13.4/6.7 A
-
Insulation Class: B
-
Item: Pentair/Pac Fab Replacement Pump Motor
-
Motor Shaft Rotation: CW/CCW
-
Motor Thermal Protection: None
-
Mounting Position: Horizontal
-
Mounting Type: C-Face, No Base
-
Number of Speed: 1-Speed
-
Overall Length: 14.90 Inch
-
RPM: 3450
-
Service Factor: 1.00
-
Shaft Design: Threaded
-
Shaft Diameter: 5/8 Inch
-
Shaft Length: 11/16 Inch
-
Shaft Material: 303 Stainless Steel
-
Standards Approvals: UL 1081 Approved, UL Recognized (E44549), CSA Certified
-
Sub Brand: Century®
-
Type: SC
-
Voltage Rating: 208-230/460 V
-
Application: Pool/Spa Motor
-
Manufacturer Part Number: 18409300
-
MPN: H995
-
UPC: 786674025180
-
Country of Origin: United States
