Regal Beloit H887L Century General Purpose Motor 3.0 HP 3 Ph 60 Hz 230/460 V

Product Description

The Regal Beloit H887L Century General Purpose Motor offers 3.0 HP at 230/460 V, 60 Hz, and operates at 1800 RPM. This three-phase motor features a 56HZ frame with an Open Drip Proof (ODP) design for effective performance.

• UL recognized and CSA certified for safety in various applications.
• Permanently lubricated sealed bearings enhance motor longevity.
• Sturdy rolled steel construction adds to the motor’s durability.

Product Highlights

This motor is designed for continuous duty and includes thermal protection, ensuring reliability in demanding environments.

Product Information

Standard Information

• Brand: Regal Beloit
• MPN: H887L

Technical Specifications

• Phase: 3
• Output HP: 3.0 HP
• Output KW: 2.2 kW
• Voltage: 230/460 V
• Speed: 1750 RPM
• Service Factor: 1
• Frame: 56HZ
• Enclosure: Open Drip Proof
• Thermal Protection: Thermally Protected
• Efficiency: 78.5%
• Ambient Temperature: 40 °C
• Frequency: 60 Hz
• Current: 9/4.5 A
• Duty: Continuous
• Insulation Class: F
• UL: Recognized
• CSA: Y
• CE: N
• Number of Speeds: 1
• Electrical Type: Polyphase, Induction
• Starting Method: Across The Line
• Poles: 4
• Rotation: Reversible Counterclockwise
• Mounting: Rigid Base
• Drive End Bearing: Ball
• Opp Drive End Bearing: Ball
• Frame Material: Rolled Steel
• Shaft Type: Keyed
• Overall Length: 14.56 inches
• Frame Length: 8.75 inches
• Shaft Diameter: 0.875 inches
• Shaft Extension: 2.31 inches
• Frame Size: 56H
• RPM: 1725
• Speeds: 1
