Fasco D1170 1/15hp 1550 RPM CW 115 Volts Fan Motor Replacement For Jenn Air 80CR

Product Description

The Fasco D1170 fan motor is a general-purpose motor ideal for various applications. This motor is designed with a power rating of 1/15 horsepower and operates at 1550 RPM. Suitable for use in electrical and HVAC systems, it provides reliable performance. The motor has a voltage rating of 115 volts and features a 4.4-inch diameter.

• Designed for multiple applications
• Operates at 115 volts and 1550 RPM
• Includes thermal protection

Product Highlights

This motor is thermally protected and rotates clockwise at the shaft end. It is UL recognized and CSA certified for safety and reliability.

Product Information

Standard Information

• Brand: Fasco
• Model: D1170

Technical Specifications

• Horsepower: 1/15 HP
• Speed: 1550 RPM
• Voltage: 115 Volts
• Amperage: 2.1 A
• Diameter: 4.4 inches
• Length: 7.24 inches
• Shaft Diameter: 0.375 inches
• Shaft Length: 2.5 inches
• Mounting: Extended Stud
• Bearing Type: Ball
• Rotation: Clockwise Shaft End
• Enclosure: Open Air-Over
• Insulation Class: A
• Frame Material: Rolled Steel
• Certification: UL, CSA
