Regal Beloit B2859 2 HP Square Flange Up-Rated Pool & Spa Pump Motor 56Y Threaded Shaft

Product Description

The Regal Beloit B2859 is a 2 HP square flange, up-rated pool and spa pump motor with a 56Y threaded shaft. Designed for swimming pools, this motor helps maintain your pool with less time and effort. It operates at 3450 RPM with a voltage of 115/230V.

• Square flange (face)
• Threaded shaft
• Capacitor start
• All copper windings
• Automatic thermal protection
• Stainless steel threaded shaft
• Sealed ball bearings

Product Highlights

This Regal Beloit motor features a square flange, threaded shaft, capacitor start, and automatic thermal protection.

Product Information

Standard Information

• Brand: REGAL BELOIT
• Manufacturer Part Number: B2859
• Country of Origin: China

Technical Specifications

• Speed: 1 Speed (1-Spd)
• Voltage: 115 & 230V
• Motor Frame: 56Y
• HP: 2 HP
• Amps: 11.2/22.4 amp
• Commonly Used On: Sta-Rite: Max-E-Glas, Max-E-Glas II, Dura-Glas, Dura-Glas II, Dyna-Glas, Dyna-Max. Pentair: Whisperflo, Challenger, Pinnacle and Anthony AR2 Series
• Motor Type: Pool
• Motor Amperage: 21.0A/10.5A
• Phase: 1 Phase (1ph)
• Frame Type: 56Y
• Horsepower: 2.0hp
• Total Horsepower: 2.2thp
• Motor Shaft Type: Threaded
• Motor Style: Square Flange
• Capacitor On Top: Yes
• Manufacturer: Century
• Minimum Pump Power Requirement: 2 hp
• Type: Standard Pool Pump
• Model: Century B2859
• MPN: B2859
• Features: Single-Speed
• Suitable For: In Ground Pools
• Power: 1471 W
• VoltageRating: 115/230 V
• DutyCycle: Continuous
• MotorDesign: PSC
• FullLoadAmps: 11.2/22.4 A
• ServiceFactor: 1.10
• Brand: Regal Beloit
• SubBrand: Century®
• StandardsApprovals: UL 1081 Approved, CSA Certified
• AmbientTemperature: 50 deg C
• RPM: 3450
• ShaftDesign: Threaded
• MotorShaftRotation: CCWPE
• FlangeMaterial: Aluminum
• ShaftMaterial: 303 Stainless Steel
• MountingType: C-Face, No Base
• InsulationClass: B
• EfficiencyGroup: Standard
• ThrustHorsepower: 2.2
• ShaftDiameter: 5/8 Inch
• FrequencyRating: 60 Hz
• OverallLength: 14.40 Inch
• Diameter: 6-1/2 Inch
• Item: Pool and Spa Pump Motor
• ShaftLength: 7/16 Inch
• MotorThermalProtection: Auto
• Bearing Type: Ball
• EnclosureDesign: Open Dripproof
• FlangeType: Square
