Regal Beloit America - EPC D367 FASCO Fan Coil & Air Conditioner Motor

Product Description

The Regal Beloit America - EPC D367, also known as the FASCO Fan Coil & Air Conditioner Motor, is specifically designed for use in window air-conditioning units. This motor operates as a shaded pole unit and features a diameter of three point three inches. It is thermally protected to ensure reliable performance while operating in various conditions.

• Designed for window air-conditioning motor applications
• Features a three point three inch diameter with shaded pole design
• Thermally protected with Class B insulation for durability

Product Highlights

This motor includes an open air over (OAO) enclosure with Class B insulation, which is suitable for ambient temperatures up to forty degrees Celsius. It operates effectively with sleeve bearings and provides reliable service in HVAC applications.

Product Information

Standard Information

• Brand: Regal Beloit America - EPC
• MPN: D367

Technical Specifications

• Phase: 1
• Output HP: 1/10 - 1/15 - 1/30 HP
• Output KW: 0.07 kW
• Voltage: 115 V
• Speed: 1550 rpm
• Service Factor: 1
• Frame: 3.3 inches
• Enclosure: Open Air Over
• Thermal Protection: Thermally Protected
• Ambient Temperature: 40 degrees Celsius
• Frequency: 60 Hz
