Regal Beloit 1512STD MAR Heavy Duty Terminal BLK 600-Volt 12-Pole 30-Amp GP Phenolic

Product Description

The Regal Beloit 1512STD MAR Heavy Duty Terminal Block is designed for robust electrical connections. This terminal block operates at 600 volts and supports up to 30 amps, making it suitable for various applications in electrical systems.

• Constructed for 22 to 10 AWG wire
• Features a threaded terminal for secure connections
• Surface mount design for easy installation

Product Highlights

This heavy-duty terminal block is ideal for electrical wiring projects that require durable and reliable connections. It is part of the Series 1500 and offers a temperature rating of 150 degrees Celsius.

Product Information

Standard Information

• Manufacturer: Regal Beloit
• MPN: 1512STD

Technical Specifications

• Amperage Rating: 30 A
• Voltage Rating: 600 VAC/VDC
• Number of Poles: 12
• Wire Strip Length: 8-1/4 inches
• Material: Phenolic
• Dimensions: 8.25 inches L x 2 inches W x 1.19 inches D
• Temperature Rating: 150 degrees Celsius
• Torque Rating: 20 in-lb
• Standards: UL, CSA, CE Certified, RoHS Compliant
• Mounting Type: Surface
• Spacing: 5/8 inches
