Reflectix HVBP1610003 Double Bubble Duct Wrap 16in X 100ft

Product Description

The REFLECTIX HVBP1610003 is a double bubble polyethylene duct wrap insulation rated at R-4.2, designed for wrapping both rectangular and round ductwork in residential and commercial HVAC systems. At 5/16 inches thick and 16 inches wide on a 100-foot roll, this wrap provides a fiber-free, lightweight insulation solution that resists conductive heat flow through two inner bubble layers and a center polyethylene core. Licensed HVAC technicians and sheet metal installers use it to reduce heat gain and loss in duct runs, helping maintain consistent supply air temperatures throughout the system. The product carries ETL certification for both the US and Canada and meets ASHRAE, SMACNA, and ACCA standards.

HVBP1610003 is suited for HVAC duct insulation applications in new construction and retrofit jobs. The standard edge format makes it straightforward to wrap and lap on straight runs and fittings. Its moisture-resistant polyethylene construction holds up in unconditioned spaces such as attics, crawlspaces, and mechanical rooms where humidity levels fluctuate. The 100-foot roll length is practical for larger duct installations without excessive seaming. Each case contains 3 rolls, covering significant linear footage per order. The temperature operating range of -60 degrees F to 180 degrees F accommodates both heating and cooling duct systems.

Key Features

• R-4.2 thermal resistance with a double bubble layer construction that resists conductive heat flow
• 5/16 inches thick polyethylene material — fiber-free, non-toxic, and non-carcinogenic
• Resists moisture, humidity, and the growth of fungi, mold, and mildew
• ETL listed for US and Canada; meets ASTM, ASHRAE, SMACNA, ACCA, and ISO 9001 standards
• Does not require protective clothing or respirators for installation
• Lightweight construction reduces labor time compared to fiberglass duct wrap
• Made in the USA

Compatibility

Designed for wrapping rectangular and round ductwork in HVAC system applications, consistent with SMACNA and ACCA installation guidelines for duct insulation.

Installation Notes

Installation is typically performed by licensed HVAC technicians or sheet metal contractors following local mechanical codes and SMACNA duct insulation guidelines. Power down the air handling system before beginning work on duct runs. Secure the wrap with approved foil tape or mechanical fasteners at all seams and edges to maintain thermal continuity and prevent air bypass. No respirator or protective clothing is required for handling this product.

Technical Specifications

• Insulation Type: Double Bubble Layer, Standard Edge
• R-Value: R-4.2
• Insulation Thickness: 5/16 inches
• Roll Dimensions: 16 inches wide x 100 feet long
• Material: Polyethylene
• Maximum Temperature Rating: 180 degrees F
• Minimum Temperature Rating: -60 degrees F
• Package Weight: 20 pounds
• Application: HVAC Duct Insulation
• Certifications: ETL (US and Canada), ISO 9001, ASHRAE, SMACNA, ACCA, HARDI
• Applicable Standards: ASTM C335, C411, E84, C1224, C423, E795, E96, D751, C1668, E84-08, C1338-00
• Country of Origin: USA
• Quantity per Case: 3 rolls

Standard Information

• Brand: REFLECTIX
• Manufacturer Part Number: HVBP1610003
