Red-White Valve 236AB 3/4 Brass FNPT Swing Check Valve

Product Description

The Red-White Valve 236AB 3/4 in. Brass FNPT Swing Check Valve is designed to prevent backflow in plumbing systems. This valve is suitable for use in various applications where reliable flow direction is necessary. It features a brass body and low lead compliance, making it a safe choice for drinking water systems.

• Brass construction for durability and corrosion resistance
• Low lead compliance for safety in potable water applications
• Designed to ensure effective closure to prevent backflow

Product Highlights

The swing check valve operates efficiently to allow fluid flow in one direction and closes automatically when flow stops, preventing reverse flow.

Product Information

Standard Information

• Manufacturer: Red-White Valve
• Type: Y-Pattern

Technical Specifications

• MPN: 236AB 3/4
• Body Material: Brass
• Inlet to Outlet Length: 2.76 in
• Top to Inlet Center: 1.97 in
• Pressure Rating: 200 psi
• Pressure Class: 200 lb WOG
• Temperature Rating: 15 to 160 deg F
• Softgoods Material: Virgin PTFE
