Red-White Valve 236AB 1-1/4 Brass FNPT Swing Check Valve

Product Description

The Red-White Valve 236AB 1-1/4 is a brass FNPT swing check valve designed for various plumbing applications. This valve ensures smooth liquid flow while preventing backflow, making it essential for effective system operation.

• Constructed with low lead brass for safety compliance.
• Features a wye pattern design for optimal flow dynamics.
• Rated for pressures of up to 200 psi.

Product Highlights

Durable and compliant, suitable for domestic and commercial plumbing.

Product Information

Standard Information

• Manufacturer: Red-White Valve Corp
• Type: Y-Pattern Swing Check Valve

Technical Specifications

• Body Material: Brass
• End Style: FNPT
• Inlet to Outlet Length: 3.78 inches
• Low Lead Compliance: Yes
• Nominal Size: 1-1/4 inches
• Pressure Class: 200 lb WOG
• Pressure Rating: 200 psi
• Series: 236AB
• Softgoods Material: Virgin PTFE
• Temperature Rating: 15 to 160 degrees F
• Top to Inlet Center: 2.71 inches
• Trim Material: Brass
