Red-White Valve 207AB 1/2 Low Lead Gate CXC

Product Description

The Red-White Valve model 207AB 1/2 is a low lead gate valve designed for efficient fluid control. This valve features a solder end style, making it suitable for various plumbing applications. It meets the industry standards for safety and reliability.

• Nominal size of one half inch
• Pressure rating of 200 lb WOG and 125 lb WSP
• Handwheel actuator for easy operation

Product Highlights

This gate valve ensures reliable performance with its solid construction. The brass body and aluminum/brass trim contribute to its durability.

Product Information

Standard Information

• Manufacturer: Red-White Valve Corp
• Part Number: 207AB 1/2

Technical Specifications

• Actuator Type: Handwheel
• Body Material: Brass
• End Style: Solder
• Hand Wheel Diameter: 2.51 inches
• Inlet to Outlet Length: 1.97 inches
• Nominal Size: 1/2 inches
• Pressure Rating: 200 lb WOG / 125 lb WSP
• Series: 207AB
• Softgoods Material: Graphite Packing Ring
• Top to Inlet Center: 2.79 inches
• Trim Material: Aluminum/Brass
