Rectorseal usa2223ba Dual Run Capacitor 80+10 Mfd 370/440V

Product Description

The RECTORSEAL usa2223ba is a dual run capacitor rated at 80+10 microfarads (MFD) and 370/440 volts, designed for single-phase HVAC motors in residential and light commercial equipment. It serves both the compressor and fan motor circuits simultaneously from a single round housing, reducing the number of discrete components in the electrical panel. The unit measures 2.5 inches in diameter with a case height of 5.7 inches. A double-rolled cover provides a leak-proof enclosure, and the capacitor is encapsulated in thick non-PCB dielectric fluid to limit heat buildup during continuous operation. Licensed HVAC technicians install this capacitor as a direct replacement when a failed dual run capacitor causes hard-start conditions or motor failure to run.

This capacitor is suited for residential and light commercial air conditioning systems where the condensing unit requires a single round dual run capacitor to power both the compressor and the condenser fan motor. The 370/440V dual voltage rating provides flexibility across a range of equipment voltage configurations. It is part of the USA-Made Capacitors series and is manufactured domestically. HVAC service technicians commonly use this part during seasonal maintenance calls and emergency no-cool service calls when capacitor failure is confirmed through capacitance testing.

Key Features

• Dual run capacitor powers compressor and fan motor circuits from one component
• 80+10 MFD rating supports common condensing unit motor combinations
• 370/440V dual voltage rating compatible with standard single-phase HVAC equipment voltage ranges
• Double-rolled cover creates a leak-proof enclosure
• Non-PCB dielectric fluid encapsulation reduces internal operating heat
• Round form factor at 2.5 inches diameter fits standard capacitor mounting brackets

Compatibility

Designed as an OEM-style replacement dual run capacitor for residential and light commercial single-phase air conditioning condensing units requiring an 80+10 MFD, 370/440V round capacitor.

Installation Notes

Installation should be performed by a licensed HVAC technician. Disconnect and lock out all power to the condensing unit before removing the access panel or touching any capacitor terminals, as capacitors store a lethal charge even after power is removed — discharge the capacitor safely using an appropriate resistive discharge tool before handling. Confirm MFD rating and voltage rating match the equipment nameplate before installing the replacement. Follow applicable local electrical codes and the equipment manufacturer's service instructions when securing wiring and mounting the capacitor.

Technical Specifications

• MFD Rating: 80+10 MFD
• Voltage Rating: 370/440V
• Shape: Round
• Diameter: 2.5 inches
• Case Height: 5.7 inches
• Series: USA-Made Capacitors

Standard Information

• Brand: RECTORSEAL
• Manufacturer Part Number: usa2223ba
