Rectorseal usa2031 Oval Run Capacitor 7.5 Mfd

Product Description

The RECTORSEAL usa2031 is a single-configuration oval run capacitor rated at 7.5 microfarads (MFD) and compatible with 370/440-volt systems. Run capacitors provide continuous phase-shifted current to motor windings, keeping compressors and fan motors running at correct speed and efficiency after startup. This unit ships in an oval housing, which fits the majority of standard capacitor brackets found in residential and light-commercial HVAC equipment. Installation is performed by licensed HVAC technicians during routine maintenance, system repair, or motor replacement calls.

The usa2031 is suited for use in split-system air conditioners, heat pumps, and package units where a single run capacitor is required for either a condenser fan motor or a compressor. Its dual-voltage rating of 370/440 volts makes it adaptable across a wide range of residential and light-commercial equipment without requiring separate part numbers for each voltage class. Technicians servicing aging equipment or performing capacitor-bank refreshes will find this part straightforward to cross into standard single-capacitor positions.

Key Features

• 7.5 MFD capacitance for single-motor run applications
• Dual-voltage rating of 370/440 volts covers a broad equipment range
• Oval housing fits most standard HVAC capacitor mounting brackets
• Single-connection configuration simplifies wiring during replacement
• Run-capacitor design provides continuous duty operation, not just start assist

Compatibility

Designed as an OEM-style replacement run capacitor for residential and light-commercial HVAC systems requiring a single oval-style capacitor rated at 7.5 MFD and 370 or 440 volts.

Installation Notes

Run capacitor replacement is a task for qualified HVAC technicians. Disconnect and lock out all power to the unit before handling capacitors, as capacitors can retain a dangerous charge even after power is removed — discharge the capacitor through a resistor before touching terminals. Confirm the MFD rating and voltage rating of the replacement match or exceed the original equipment specification before installation. Follow all applicable local codes and manufacturer service instructions.

Technical Specifications

• Type: Run Capacitor
• Configuration: Single
• Capacitance: 7.5 MFD
• Voltage Rating: 370/440 volts
• Shape: Oval
• Connection Type: Single

Standard Information

• Brand: RECTORSEAL
• Manufacturer Part Number: usa2031
