Rectorseal n4161 Contactor 2 Pole 40 Amps 24 Volts

Product Description

The RECTORSEAL n4161 is a 2-pole definite-purpose contactor rated at 40 amps with a 24-volt coil, designed for switching high-voltage load circuits in HVAC equipment. Contactors of this type serve as the primary switching device that energizes compressors and condenser fan motors in response to a low-voltage thermostat signal. The 24-volt coil allows direct integration with standard residential and light-commercial thermostat control wiring. Licensed HVAC technicians install this component during service calls involving failed or pitted contacts, coil burnout, or as part of a preventive maintenance replacement program on aging condensing units.

This contactor is suited for use in residential and light-commercial split-system air conditioners and heat pumps, specifically within the outdoor condensing unit. It is positioned in the control circuit to handle the high-amperage load of single-phase compressors and condenser fan motors. The 40-amp rating supports the load requirements common to mid-range residential condensing units. Installation typically takes place during cooling season service, compressor replacement, or electrical troubleshooting when the existing contactor shows signs of contact wear, coil failure, or voltage drop across closed contacts.

Key Features

• 2-pole configuration for switching two load legs simultaneously
• 40-amp continuous load rating suitable for residential compressor loads
• 24-volt coil integrates directly with standard thermostat low-voltage control circuits
• Definite-purpose design intended for HVAC compressor and motor switching applications

Compatibility

Designed as an OEM-style replacement contactor for residential and light-commercial split-system air conditioners and heat pump condensing units requiring a 2-pole, 40-amp, 24-volt definite-purpose contactor.

Installation Notes

A licensed HVAC technician should perform contactor replacement. Disconnect and lock out all power to the condensing unit at the disconnect box before handling any electrical components. Photograph or document existing wiring terminations before removing the old contactor to ensure correct wire placement on the replacement unit. NEC guidelines apply to all electrical work on HVAC equipment.

Technical Specifications

• Number of Poles: 2
• Amperage Rating: 40 amps
• Coil Voltage: 24 volts

Standard Information

• Brand: RECTORSEAL
• Manufacturer Part Number: n4161
