Rectorseal M22731 Condenser Fan Motor 3/4 Hp 208/230V

Product Description

The RECTORSEAL M22731 is a condenser fan motor rated at 3/4 horsepower, 208/230 volts, and 1075 RPM. It is designed for use in air-cooled condensing units where reliable airflow across the condenser coil is critical to system efficiency. Running at 1075 RPM, this motor moves air at a speed suited to standard residential and light commercial condenser fan applications. Licensed HVAC technicians install this motor as a direct replacement or service part in split-system air conditioners and heat pumps.

This motor is intended for outdoor condensing unit applications where the fan blade is mounted to the motor shaft to draw or push air across the condenser coil. It is commonly found in residential split-system cooling equipment and light commercial packaged units. The 208/230-volt dual-voltage rating makes it compatible with the single-phase power supply found in most residential and small commercial installations. An HVAC technician performing a seasonal service call or emergency repair would source this motor to restore condenser airflow and system operation.

Key Features

• 3/4 HP output suited for standard condenser fan blade loads
• Dual-voltage 208/230-volt rating covers a wide range of single-phase supply configurations
• 1075 RPM operating speed matched to typical condenser fan airflow requirements
• Designed for outdoor condensing unit service and replacement applications

Compatibility

Designed as an OEM-style replacement condenser fan motor for residential and light commercial split-system air conditioners and heat pumps using a 3/4 HP, 208/230-volt, 1075 RPM single-phase motor.

Installation Notes

Installation should be performed by a licensed HVAC technician. Disconnect and lock out all electrical power to the condensing unit before removing the existing motor or handling wiring. Verify shaft rotation direction and blade pitch are correct for the specific unit before securing the motor and restoring power. Follow applicable NEC requirements for disconnect means and wiring methods when replacing condenser fan motors.

Technical Specifications

• Horsepower: 3/4 HP
• Voltage: 208/230 volts
• Speed: 1075 RPM

Standard Information

• Brand: RECTORSEAL
• Manufacturer Part Number: M22731
