Rectorseal M22590 Condenser Fan Motor 3/4 Hp 208/230V

Product Description

The RECTORSEAL M22590 is a condenser fan motor rated at 3/4 horsepower and designed for 208/230-volt single-phase applications. It operates at 1075 RPM with three selectable speed taps, giving technicians the flexibility to match airflow to system requirements. The reversible rotation feature allows the motor to be configured for either clockwise or counterclockwise shaft rotation, making it adaptable for a range of condenser fan assemblies. Licensed HVAC technicians typically install this motor as a direct replacement in residential and light-commercial cooling equipment during seasonal maintenance or unplanned service calls.

This motor is suited for outdoor condenser unit applications where the fan must move air across the condensing coil. The three-speed capability and reversible design make it a practical service replacement across a variety of condenser fan configurations. It is commonly installed in split-system air conditioners and heat pump outdoor units where the original motor has failed or is operating outside acceptable performance parameters.

Key Features

• 3/4 HP output suitable for standard residential and light-commercial condenser fan loads
• 208/230-volt dual-voltage design accommodates common single-phase power supplies
• 1075 RPM operating speed typical of condenser fan motor applications
• Three-speed tap configuration allows field-adjustment of airflow
• Reversible rotation eliminates the need to stock separate clockwise and counterclockwise motors

Compatibility

Designed as an OEM-style replacement condenser fan motor for residential and light-commercial split-system air conditioners and heat pumps requiring a 3/4 HP, 208/230-volt, 1075 RPM, 3-speed reversible motor.

Installation Notes

Installation should be performed by a licensed HVAC technician. Disconnect and lock out all power to the condensing unit before removing the existing motor or disturbing any wiring. Verify that the replacement motor shaft diameter, mounting configuration, and rotation direction match the existing fan blade and mounting bracket before energizing the unit. Follow all applicable local codes and manufacturer wiring diagrams when connecting speed-tap leads.

Technical Specifications

• Horsepower: 3/4 HP
• Voltage: 208/230 volts
• Speed: 1075 RPM
• Number of Speeds: 3
• Rotation: Reversible

Standard Information

• Brand: RECTORSEAL
• Manufacturer Part Number: M22590
