Rectorseal M22588 Condenser Fan Motor 1/2 Hp 208/230V

Product Description

The RECTORSEAL M22588 is a 1/2 HP condenser fan motor rated for 208/230 volt operation at 1075 RPM with three selectable speeds and reversible rotation. This motor is built for outdoor condensing unit service in residential and light commercial HVAC systems. The reversible shaft rotation allows the motor to be configured for different fan blade orientations during installation. HVAC technicians install this motor as a direct replacement in split-system air conditioners and heat pumps where the original condenser fan motor has failed.

This motor is suited for residential split-system condensing units and light commercial packaged equipment where a 1/2 HP, 208/230 volt, 1075 RPM condenser fan motor is specified. The three-speed capability gives the installer flexibility to match the original equipment fan speed without swapping components. Reversible rotation eliminates the need to stock separate clockwise and counterclockwise units, making it a practical universal-style replacement for common condenser fan motor applications.

Key Features

• 1/2 HP output rated for condenser fan duty
• 208/230 volt dual-voltage operation
• 1075 RPM operating speed
• Three selectable speed taps for flexible configuration
• Reversible rotation for clockwise or counterclockwise fan blade mounting

Compatibility

Designed as an OEM-style replacement condenser fan motor for residential and light commercial split-system air conditioners and heat pumps requiring a 1/2 HP, 208/230 volt, 1075 RPM three-speed reversible motor.

Installation Notes

Installation should be performed by a licensed HVAC technician. Disconnect and lock out all power to the condensing unit before removing the original motor. Confirm the replacement motor shaft diameter, mounting configuration, and capacitor rating match the original equipment requirements before wiring. Dispose of or recycle the old motor in accordance with local regulations.

Technical Specifications

• Horsepower: 1/2 HP
• Voltage: 208/230 volts
• Speed: 1075 RPM
• Number of Speeds: 3
• Rotation: Reversible

Standard Information

• Brand: RECTORSEAL
• Manufacturer Part Number: M22588
