Rectorseal M19550 Condenser Fan Motor 1/2 Hp 460V

Product Description

The RECTORSEAL M19550 is a condenser fan motor rated at 1/2 horsepower and 1075 RPM, designed for use in HVAC condensing units. Operating on 460 volts, this motor drives the condenser fan blade to move air across the coil and maintain proper heat rejection in the refrigerant circuit. It is a direct replacement-style motor intended for installation by licensed HVAC technicians during routine maintenance, compressor section service, or motor failure calls. The 1075 RPM operating speed is standard for residential and light commercial condenser fan applications.

This motor fits into condensing unit applications where a 460-volt, 1/2 HP condenser fan motor is specified. It is suited for commercial HVAC environments where 460-volt three-phase or single-phase power distribution is standard. Typical install scenarios include rooftop units, split-system condensing sections, and packaged equipment in light commercial settings. Always verify voltage, horsepower, RPM, shaft size, and rotation direction against the original equipment nameplate before installation.

Key Features

• 1/2 HP output for standard condenser fan drive applications
• 1075 RPM operating speed matched to common condenser fan blade requirements
• 460-volt rating suited for commercial-grade electrical distribution
• OEM-style replacement design for condensing unit service calls

Compatibility

Designed as an OEM-style replacement condenser fan motor for 460-volt HVAC condensing units requiring a 1/2 HP, 1075 RPM motor. Confirm shaft diameter, rotation, and mounting configuration against the original unit nameplate before ordering.

Installation Notes

Installation should be performed by a licensed HVAC technician. Disconnect and lock out all electrical power to the condensing unit before removing the existing motor. Verify rotation direction, shaft length, and mounting bracket configuration before securing the replacement motor. Follow all applicable NEC requirements for motor replacement and reconnection of electrical leads.

Technical Specifications

• Horsepower: 1/2 HP
• Speed: 1075 RPM
• Voltage: 460 volts
• Application: Condenser Fan

Standard Information

• Brand: RECTORSEAL
• Manufacturer Part Number: M19550
