Rectorseal m10591 Direct Drive Motor 1HP 1075RPM 115V

Product Description

The RECTORSEAL m10591 is a direct drive blower motor rated at 1 horsepower and 1,075 RPM, designed for use in forced-air HVAC systems. Operating on 115 volts single phase, this motor delivers five speed selections to match airflow requirements across a range of residential and light commercial air handler and furnace applications. Licensed HVAC technicians install this motor as an OEM-style replacement when the original blower motor fails or shows signs of thermal overload, bearing wear, or capacitor-related failure. Its multi-speed capability allows the installing tech to match static pressure and CFM requirements to the specific system configuration.

This motor is suited for direct drive blower assemblies in forced-air heating and cooling equipment. The five-speed winding configuration supports variable airflow staging in systems that use multi-tap control boards or furnace control modules to switch between heating, cooling, and continuous fan speeds. It is appropriate for residential and light commercial installations where a 115-volt single-phase power supply is present and the blower wheel mounts directly to the motor shaft without a belt or pulley drive system.

Key Features

• 1 HP output rating for robust airflow performance in full-size air handler and furnace blower assemblies
• 1,075 RPM operating speed standard for direct drive blower applications
• 115-volt single-phase input compatible with standard residential electrical supply
• Five speed taps allow airflow matching to system static pressure requirements
• OEM-style replacement designed to restore original equipment performance

Compatibility

Designed as an OEM-style replacement for direct drive blower motors in residential and light commercial forced-air HVAC equipment requiring a 1 HP, 1,075 RPM, 115-volt single-phase motor with five speed taps.

Installation Notes

A licensed HVAC technician should perform this replacement in accordance with local mechanical codes and NEC requirements. Disconnect and lock out all electrical power to the air handler or furnace before removing the existing motor. Verify that the replacement motor shaft diameter and rotation direction match the original before securing the blower wheel and reconnecting speed-tap wiring. Do not energize the motor without confirming that all wiring terminations are secure and that the blower wheel spins freely without obstruction.

Technical Specifications

• Horsepower: 1 HP
• Speed: 1,075 RPM
• Voltage: 115 volts
• Phase: Single phase
• Number of Speeds: 5
• Drive Type: Direct drive

Standard Information

• Brand: RECTORSEAL
• Manufacturer Part Number: m10591
