Rectorseal M10590 Direct Drive Blower Motor 3/4 Hp

Product Description

The RECTORSEAL M10590 is a direct drive blower motor rated at 3/4 HP and designed for single-phase, 208-230 volt applications. It operates at 1075 RPM with a PSC (Permanent Split Capacitor) motor design and features reversible rotation, giving installers flexibility during replacement or new installation. The motor runs on sleeve bearings, is rated for continuous duty, and includes automatic thermal protection. With a 6-pole configuration and a service factor of 1.0, the M10590 is built for reliable, sustained operation in forced-air systems.

This motor is suited for residential and light commercial HVAC applications where a direct drive blower is used in air handlers, furnaces, or fan coil units. The three-speed configuration supports variable airflow setups common in multi-stage or zoned systems. Licensed HVAC technicians performing blower motor replacements or new equipment installations will find the reversible rotation and standard mounting design straightforward to work with in typical indoor blower assemblies.

Key Features

• 3/4 HP continuous duty rating for sustained blower operation
• PSC motor type for efficient single-phase performance
• Reversible rotation for flexible installation orientation
• Three-speed output supporting variable airflow configurations
• Automatic thermal protection guards against overload conditions
• Sleeve bearing construction with OAO (Open Air Over) enclosure

Compatibility

Designed as an OEM-style direct drive blower motor replacement for residential and light commercial HVAC air handlers, furnaces, and fan coil units requiring a 3/4 HP, 208-230 volt, 1075 RPM single-phase PSC motor.

Installation Notes

Installation should be performed by a licensed HVAC technician. Disconnect and lock out all power to the air handling unit before removing the existing motor or making any wiring connections. Confirm rotation direction before final installation, as the reversible rotation feature requires correct setting for proper airflow through the blower wheel. Follow NEC guidelines and local electrical codes for motor wiring and circuit protection requirements.

Technical Specifications

• Horsepower: 3/4 HP
• Voltage: 208-230 volts
• Motor Type: PSC
• Phase: Single
• RPM: 1075
• RPM Range: 925-1200
• Speeds: 3
• Number of Poles: 6
• Rotation: Reversible
• Duty: Continuous
• Thermal Protection: Automatic
• Service Factor: 1.0
• Bearing Type: Sleeve
• Enclosure: OAO

Standard Information

• Brand: RECTORSEAL
• Manufacturer Part Number: M10590
