Rectorseal M10586 Direct Drive Psc Motor 1/3 Hp 208-230V

Product Description

The RECTORSEAL M10586 is a direct drive PSC (permanent split capacitor) motor rated at 1/3 horsepower and designed for 208-230 volt single-phase power. Running at 1075 RPM with a speed range of 925 to 1200 RPM, this 6-pole motor delivers three selectable speeds for flexible airflow control. It features an open air-over (OAO) enclosure, sleeve bearings, automatic thermal protection, and a continuous duty rating. Licensed HVAC technicians install this motor as a replacement in residential and light commercial air handling applications where a direct drive configuration is required.

This motor is suited for direct drive blower and fan applications in forced-air HVAC systems. The reverse (REV) rotation and three-speed capability make it appropriate for multi-speed air handler and evaporator coil blower assemblies. The OAO enclosure allows cooling airflow from the moving air stream, which is standard for indoor blower compartment installations. A service factor of 1.0 and continuous duty rating indicate the motor is engineered for uninterrupted operation in normal HVAC cycling conditions.

Key Features

• 1/3 HP PSC motor with 208-230 volt single-phase input
• 1075 RPM base speed with 925 to 1200 RPM operating range
• Three selectable speeds for multi-speed blower compatibility
• Open air-over (OAO) enclosure designed for blower compartment airflow cooling
• Automatic thermal protection with continuous duty rating
• Reverse rotation (REV) configuration for direct drive blower assemblies
• Sleeve bearings for quiet, low-maintenance operation

Compatibility

Designed as an OEM-style direct drive replacement motor for residential and light commercial forced-air HVAC blower assemblies requiring a single-phase, 208-230 volt PSC motor at 1/3 HP.

Installation Notes

Installation should be performed by a licensed HVAC technician. Disconnect and lock out all electrical power to the air handler or furnace before removing the existing motor. Verify that the replacement motor rotation, shaft diameter, and mounting configuration match the original unit before completing installation. Follow all applicable NEC requirements for motor branch circuit wiring and grounding.

Technical Specifications

• Horsepower: 1/3 HP
• Voltage: 208-230 volts
• Motor Type: PSC (Permanent Split Capacitor)
• Phase: Single
• RPM: 1075
• RPM Range: 925-1200
• Number of Poles: 6
• Speeds: 3
• Rotation: Reverse (REV)
• Enclosure: OAO (Open Air-Over)
• Bearing Type: Sleeve
• Duty: Continuous
• Thermal Protection: Automatic
• Service Factor: 1.0

Standard Information

• Brand: RECTORSEAL
• Manufacturer Part Number: M10586
