Rectorseal M10584 Direct Drive Blower Motor 1/4 Hp

Product Description

The RECTORSEAL M10584 is a direct drive blower motor rated at 1/4 horsepower, designed for continuous-duty air handling applications in residential and light commercial HVAC systems. Operating at 208-230 volts on a single-phase power supply, this PSC (permanent split capacitor) motor runs at 1075 RPM with an operating range of 925 to 1200 RPM. The 6-pole motor configuration and reverse rotation make it a fit for specific blower assemblies where counter-clockwise airflow direction is required. Thermal protection is automatic, which allows the motor to self-reset after an over-temperature event. Licensed HVAC technicians are the primary installers of this unit.

This motor is suited for direct drive blower applications in forced-air furnaces, air handlers, and fan coil units operating on 208-230 volt single-phase circuits. The OAO (open air over) enclosure allows for adequate ventilation in standard indoor mechanical spaces. Continuous duty rating means the motor is built to run for extended periods without requiring rest cycles, which is standard for HVAC blower service. It is applicable in systems requiring a reverse-rotation blower motor at the 1/4 HP capacity range.

Key Features

• 1/4 HP PSC motor built for continuous-duty blower service
• 208-230 volt single-phase operation suits common residential and light commercial supply voltages
• 1075 RPM nominal speed with a working range of 925 to 1200 RPM
• Reverse rotation for compatibility with specific direct drive blower configurations
• Automatic thermal protection with self-reset capability
• Sleeve bearing construction with OAO enclosure for standard indoor HVAC applications

Compatibility

Designed as an OEM-style replacement direct drive blower motor for residential and light commercial air handlers, furnaces, and fan coil units requiring a 1/4 HP, 208-230 volt, single-phase, reverse-rotation PSC motor at 1075 RPM.

Installation Notes

Installation should be performed by a licensed HVAC technician. Disconnect and lock out all electrical power to the air handler or furnace before removing the existing motor or making any wiring connections. Verify rotation direction matches the blower assembly requirement before energizing the system, as reversing a direct drive blower motor on an incorrect application can reduce airflow or damage the assembly. Follow local codes and the equipment manufacturer guidelines for motor mounting and electrical connections.

Technical Specifications

• Horsepower: 1/4 HP
• Voltage: 208-230 volts
• Phase: Single
• Motor Type: PSC
• RPM: 1075
• RPM Range: 925-1200
• Number of Poles: 6
• Rotation: Reverse
• Duty: Continuous
• Enclosure: OAO
• Bearing Type: Sleeve
• Thermal Protection: Automatic
• Service Factor: 1.0

Standard Information

• Brand: RECTORSEAL
• Manufacturer Part Number: M10584
