Rectorseal M08027 Belly Band Motor Mount 13 Inch

Product Description

The RECTORSEAL M08027 is a belly band motor mount designed to secure replacement condenser fan and blower motors during HVAC service and retrofit installations. The band features a 13-inch bolt pattern and is sized for use with 5.5-inch frame motors. Belly bands provide a reliable circumferential mounting solution when traditional end-mount or cradle configurations are not practical, keeping the motor firmly positioned within the unit cabinet. HVAC technicians use this type of hardware to complete motor swaps cleanly and within manufacturer-recommended mounting practices.

This belly band is intended for residential and light commercial HVAC applications where a 5.5-inch diameter motor requires a stable circumferential mount. It is a commonly specified accessory during condenser fan motor replacements, particularly when the original mounting bracket is damaged or when upgrading to an aftermarket motor that shares the same frame size. The 13-inch bolt pattern accommodates standard mounting configurations found across a wide range of rooftop and split-system condensing units.

Key Features

• 13-inch bolt pattern for secure motor positioning
• Designed for use with 5.5-inch frame motors
• Circumferential belly band design supports motors where end-mount hardware is unavailable or impractical
• Suitable for condenser fan motor replacement and retrofit applications

Compatibility

Designed for use with 5.5-inch diameter motors in residential and light commercial HVAC systems requiring a belly band mounting solution with a 13-inch bolt pattern.

Installation Notes

Installation should be performed by a qualified HVAC technician. Disconnect and lock out all electrical power to the unit before removing or installing any motor hardware. Confirm the bolt pattern and motor frame diameter match the replacement motor before securing the band. Follow equipment manufacturer guidelines and applicable local mechanical codes when completing the installation.

Technical Specifications

• Bolt Pattern: 13 inches
• Compatible Motor Frame Size: 5.5 inches

Standard Information

• Brand: RECTORSEAL
• Manufacturer Part Number: M08027
