Rectorseal M00892 Ecm Unit Bearing Motor Replaces Elco 00852

Product Description

The RECTORSEAL M00892 is a single-phase ECM unit bearing motor rated at 30 watts and designed as a direct replacement for the Elco 00852. It operates on 120 to 240 volts and runs at 1600 RPM with an operating range of 1350 to 1900 RPM. The motor features a TEAO (Totally Enclosed Air Over) enclosure for durability in airstream applications and uses electronic thermal protection rather than a traditional thermal overload device. CCW SE rotation is standard. HVAC technicians install this motor in fan coil units, evaporator blower assemblies, and similar air-handling equipment where compact, direct-drive performance is required.

This unit bearing motor is suited for residential and light commercial HVAC applications. It is a drop-in replacement for systems originally equipped with the Elco 00852, making it a practical service part for techs looking to restore airflow performance without extensive modification. Single-speed operation simplifies wiring and commissioning. The ECM motor type delivers controlled, efficient operation at a fixed speed point within the rated RPM range.

Key Features

• ECM motor type for electronically controlled, efficient operation
• TEAO enclosure rated for airstream and fan-coil environments
• 1600 RPM operating speed with a 1350-1900 RPM range
• 30-watt maximum power draw
• Electronic thermal protection replaces traditional thermal cutout
• CCW SE rotation matches common evaporator blower configurations
• Direct replacement for Elco 00852

Compatibility

Direct replacement for the Elco 00852 unit bearing motor. Suitable for single-phase, 120-240V fan coil and evaporator blower assemblies requiring a TEAO ECM unit bearing motor with CCW SE rotation.

Installation Notes

Installation should be performed by a licensed HVAC technician. Disconnect and lock out all power to the unit before removing the existing motor or handling wiring connections. Confirm shaft rotation direction and voltage supply match the replacement motor specifications before energizing. Follow applicable local codes and the equipment manufacturer's wiring diagram when reconnecting leads.

Technical Specifications

• Motor Type: ECM
• Voltage: 120-240 volts
• Wattage (Max.): 30 watts
• RPM: 1600
• RPM Range: 1350-1900
• Phase: Single
• Speeds: 1
• Rotation: CCW SE
• Enclosure: TEAO
• Bearing Type: Ball
• Thermal Protection: Electronic

Standard Information

• Brand: RECTORSEAL
• Manufacturer Part Number: M00892
