Rectorseal G 30X50 Goliath Furnace Drain Pan 30x50

Product Description

The RECTORSEAL G 30X50 is a heavy-duty condensate drain pan designed to capture and contain condensate discharge beneath furnaces, air handlers, and other indoor or rooftop HVAC equipment. Built from coated, corrosion-resistant steel engineered for continuous exposure to moisture, this pan measures 30 inches wide by 50 inches long, providing broad coverage under equipment drain points. Integrated fittings allow direct connection of condensate removal piping. Licensed HVAC technicians install this pan at primary and secondary drain locations to protect structures from water damage and maintain system integrity.

This drain pan is suited for residential and light commercial HVAC installations where equipment footprint requires extended coverage. Typical applications include placement under large air handlers, split-system evaporator coils, and furnace assemblies in attic, closet, or mechanical room settings where condensate overflow could cause structural or property damage. The 30-by-50-inch footprint accommodates equipment with wider bases that standard-size pans cannot adequately cover.

Key Features

• Coated, corrosion-resistant steel construction rated for moist HVAC service environments
• 30 inches by 50 inches footprint provides extended coverage for large equipment bases
• Integrated provisions for condensate removal piping connection
• Suitable for primary and secondary drain pan locations per accepted HVAC installation practices
• Designed to help prevent water damage from condensate overflow

Compatibility

Designed as an OEM-style replacement and new-installation drain pan for residential and light commercial furnaces, air handlers, and rooftop HVAC units requiring a 30-by-50-inch condensate collection solution.

Installation Notes

Installation should be performed by a licensed HVAC technician in accordance with applicable mechanical codes and the equipment manufacturer's instructions. Disconnect power to the HVAC system before positioning the pan and connecting any condensate piping. Ensure the pan is level and properly supported so condensate drains toward the outlet fitting without pooling. Verify that condensate drain lines are clear and correctly pitched before returning the system to service.

Technical Specifications

• Width: 30 inches
• Length: 50 inches
• Material: Coated corrosion-resistant steel

Standard Information

• Brand: RECTORSEAL
• Manufacturer Part Number: G 30X50
