Rectorseal 96415 Surge Protection Device, 120V/240V 1-Phase RSH-50

Product Description

The RECTORSEAL 96415 surge protection device is designed to protect HVAC equipment from electrical damage. It safeguards single-phase, 120/240-V air conditioning, heat pumps, and ductless mini-split systems from transient over-voltage and natural-cause surge occurrences. Easy to wire and install, it can protect residential or commercial systems.

• Surge protection device for HVAC equipment
• Protects single phase, 120/240-V air conditioning, heat pumps and ductless mini-split systems
• Easy to wire and install

Product Highlights

The surge protector fits all single phase units and features an LED light that indicates proper power surge and electrical protection with long-lasting gas discharge tube technology.

Product Information

Standard Information

• Brand: RECTORSEAL
• Manufacturer Part Number: 96415

Technical Specifications

• Type: Surge Protector
• Voltage: 120/240V
• Electrical Ratings: 120/240 VAC
• Phase: 1 ph
• Short Circuit Current Rating: 200 kA
• Specifications: 50 kA Discharge Current
• Suitable For Use With: Outside Condensing Units and Indoor Air Handlers
• Brand: Rectorseal
• Product Type: Surge Protective Device
• Applications: For Residential or Commercial Use
• Ampere Rating: 50000A Single, Up to 10000A Repetitive Surge
• MPN: 96415
