Rectorseal 86607 Cleardrain Pvc Running Trap 0.75 in SCH40

Product Description

The RECTORSEAL 86607 is a 3/4-inch Schedule 40 PVC running trap designed for condensate drainage applications in HVAC and plumbing systems. Built from Schedule 40 PVC, it provides a durable, corrosion-resistant solution for maintaining a water seal in horizontal drain lines. The running trap configuration allows it to sit inline with the drain run without requiring a vertical drop, making it a practical choice where space is limited. Licensed HVAC technicians and plumbers install this component to meet condensate trap requirements on air handlers, fan coils, and similar equipment.

This trap is suited for residential and light commercial condensate drain lines, particularly where a conventional P-trap cannot be used due to space or orientation constraints. The 3/4-inch SCH40 PVC construction is compatible with standard PVC condensate drain piping commonly found in split systems, package units, and air handler installations. Its clear or standard PVC body is appropriate for indoor drain line use where chemical resistance and ease of installation are required.

Key Features

• 3/4-inch Schedule 40 PVC construction for use in standard condensate drain systems
• Running trap design allows inline installation without a vertical offset
• Corrosion-resistant PVC material suited for condensate and drain water service
• Maintains a water seal in horizontal drain lines to prevent air bypass
• Compact form factor for installations with limited clearance

Compatibility

Designed as an OEM-style replacement or new-installation component for 3/4-inch Schedule 40 PVC condensate drain systems in residential and light commercial HVAC equipment.

Installation Notes

Installation is performed by licensed HVAC technicians or plumbers. Shut off the HVAC system and isolate the condensate drain line before beginning work. Solvent-weld connections should be made with PVC primer and cement per the fitting manufacturer instructions and applicable plumbing code. Verify trap depth meets equipment manufacturer requirements to maintain proper drain seal during system operation.

Technical Specifications

• Pipe Size: 0.75 inches
• Schedule: SCH40
• Material: PVC
• UPC: 021449866071

Standard Information

• Brand: RECTORSEAL
• Manufacturer Part Number: 86607
