Ranco O12-1549 Dual Pressure Control 24/240 V (36 inches Capillary)

Product Description

Ranco O12-1549 is a dual-pressure controller for refrigeration systems that monitors high- and low-side pressure and actuates an SPST electrical switch when setpoints are crossed. The unit is rated for 24/240 V, uses 36" capillary tubes with 1/4" SAE flare connections, and provides a low pressure range of 10 in Hg to 100 psi and a high pressure cut-out of 150 to 450 psi. It includes adjustable scale plates, automatic reset, and screw terminal connections.

• Dual pressure control with independent low (10 in Hg to 100 psi) and high (150 to 450 psi) setpoints
• Rated 24/240 V, SPST switch, automatic reset, and 36" capillary tubes with 1/4" SAE flare connections
• NEMA 1 enclosure, Super Cap capillary protection system, adjustable scale plates, and screw terminal connectors

Product Highlights

Dual-function refrigeration pressure control; 24/240 V; 36" capillary; SPST; 10 in Hg–100 psi low and 150–450 psi high ranges; 1/4" SAE connection

Product Information

Standard Information

• Brand: RANCO
• Manufacturer Part Number: O12-1549
