Ranco O10-2054 Pressure Control - Fan Cycle 100 to 400 PSIG

RANCO
Brand: RANCO
SKU: O10-2054
Availability: In Stock

Ships same day if ordered by 12 pm
$188.63
$188.63
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The RANCO O10-2054 pressure control is designed for fan cycle applications. It features a NEMA 1 enclosure with a non-conductive cover and a front-located captive cover screw. The control offers a pressure range of 100 to 400 PSIG and a differential of 40-150 PSI. It includes a 36" cap with a flare nut and SPST switch action.

  • Pressure range of 100 to 400 PSIG
  • Differential of 40-150 PSI
  • 36" capillary with flare nut

Product Highlights

This pressure control provides reliable performance in fan cycling applications, ensuring efficient operation and protection of refrigeration systems.

Product Information

Standard Information

  • Brand: RANCO
  • Manufacturer Part Number: O10-2054
  • Country of Origin: Mexico
Technical Specifications
OEM Part Number
O10-2054
OEM
Ranco
AllPoints OEM Part Number
RCOO10-2054
Unit of Stock
EA
Brand
Ranco
MPN
O10-2054
SPST
Close on High
Range
100 PSIG to 400 PSIG
Differential
40 - 150 psi
Capillary
36" Capillary with Flare Nut
Replacement for
Penn P70AA-118 and Ranco 010-2054
Vendor Name
Ranco/Robertshaw
URI Part Number
0102054
Vendor Part Number
O10-2054
Capillary Length
3'
Connection Size (In.)
1/4 Flare
Connection Type
1/4 in SAE Flared Nut Pressure
Contact Rating (Amps)
24 F.L. Amp 240 Vac
Country of Origin
MX
Gender
F
Pressure Range (psi)
100 to 400
Switch
SPST, Open Low
Note 1
Suitable for head pressure for cycling application.
Series Application
High Pressure Controls
Reset
Auto
Pressure Connection
1/4" SAE Flare Nut
Pressure Range
100 to 400 PSI (7 to 27 bar)
Comments
IP44 part number: 206-00232-002
Region
NA
Enclosure Type
NEMA 1
Series
O
Contact Configuration
SPST
Pressure Rating
100 - 400 lb/sq-in Operating, 10 - 40 psid
Material
Heavy-Duty-Plated Steel
Condition
New
Compatible Brand
Ranco O10-2054
Compatible Model
Ranco O10-2054
Compatible Product
Ranco O10-2054
Power Phase
1 Phase
Type
Condenser Fan Cycling High Pressure Refrigeration Control
Voltage
24V
Model
Ranco O10-2054
Amperage
20A
Connections
1/4" SAE Flare Nut
Switching
SPST
