Description

Product Description

Ranco O10-1418 is a single temperature control for refrigeration that uses an air coil with a remote bulb (medium) and an SPST contact. It controls temperatures from 0 to 55 °F with an adjustable differential of 3 to 20 °F. Contacts are rated for 24 A full load and 144 A locked rotor at 120/240 V, with NEMA 1 enclosure and UL approvals for refrigeration applications.

  • Air coil with remote bulb sensor (medium) and SPST contact configuration
  • Temperature range 0 to 55 °F with adjustable differential 3 to 20 °F
  • Contact ratings: 24 A full load; 144 A locked rotor at 120/240 V; pilot duty up to 720 VA; NEMA 1 enclosure; UL listed

Product Highlights

Medium-temperature refrigeration controller with air coil sensing, SPST switching, wide adjustable differential, and ratings for 120/240 V motor or compressor cycling.

Product Information

Standard Information

  • Brand: RANCO
  • Manufacturer Part Number: O10-1418
Technical Specifications
Brand
Ranco
Manufacturer Part Number
O10-1418
Series
O10
Product Type
Single temperature control
Type
Air coil with remote bulb (medium)
Capillary Type
Air coil
Sensing Element
Remote bulb
Temperature Range
0 to 55 °F
Differential Temperature Rating
3 to 20 °F
Contact Configuration
SPST
Contact Rating (Full load)
24 A at 120/240 V
Locked Rotor Amps
144 A at 120/240 V
Pilot Duty
144 VA at 24 V; 720 VA at 120/240 V; 125 VA at 241 to 600 V
Switch Action
Closes on rise (automatic reset)
Enclosure Rating
NEMA 1
Approvals/Certifications
UL (Canada and US)
Application
Self-contained refrigerator, freezer, cooler, walk-in unit, refrigeration display case
Mounting
Universal mounting
Adjustment
Seven-revolution range adjustment screws
Construction
Laser-welded bellows; compact steel case with non-conductive cover
Input Voltage
120/240 V AC
Bulb Length
1.5 in (remote bulb)
Dimensions (H x W x D)
2.75 in x 3.5 in x 2 in
Weight
1.00 lb (454 g)
