Product Description
The RAB X17FA35W is a 35W field-adjustable LED flood light suitable for various applications. This unit allows for color temperature adjustments between 3000K, 4000K, and 5000K for flexible lighting options. It includes a NEMA 7H x 7V beam distribution and an integrated photocell for automatic operation. Constructed with a die-cast aluminum body and tempered glass lens, it is rated for wet locations, complying with IP65 standards.
- Field-adjustable color temperature: 3000K, 4000K, and 5000K.
- Includes NEMA 7H x 7V beam distribution and integrated photocell.
- IP65 rated, suitable for wet environments.
Product Highlights
This flood light is ideal for outdoor settings needing reliable and adjustable lighting. It features long lifespan LEDs, robust construction, and efficient power consumption.
Product Information
Standard Information
-
Brand: RAB
-
Manufacturer Part Number: X17FA35W
Technical Specifications
-
Wattage: 35 Watts
-
Input Voltage: 120-277V
-
Color Temperature: 3000/4000/5000K
-
Lumens: 4642/5034/4864 Lumens
-
Efficacy: 129.3/135.4/145.5 lm/W
-
CRI: 80+
-
Mounting Type: Knuckle
-
Enclosure Rating: IP65
-
NEMA Beam Spread: NEMA 7H x 7V
-
Operating Temperature: -40 deg C Ambient
-
Lifespan: 100,000 Hours
-
Dimmable: 0-10V
-
Finish: Bronze
-
Construction: Precision Die Cast Aluminum
-
Lens: Tempered glass
-
Reflector: Polycarbonate
-
Power Factor: 99.3% at 120 Volt
-
Surge Protection: 6kV
-
Certifications: IP65, NEMA, UL, Wet Location, RoHS
-
Dimensions: 9-3/16 Inch Length x 7-7/16 Inch Width x 2-11/16 Inch Height
