Rab SMSBULLET2X12NA Smart Bullet LED Flood Light 26 Watts

Product Description

The RAB SMSBULLET2X12NA is a smart bullet LED flood light with motion sensor. This floodlight uses 26 watts and emits 1664 lumens of cool white light at 4000K. It features two adjustable 12W LED floodlights equivalent to 2x75W BR30/halogen/wide floods. The sensor has a 180° detection pattern up to 30 ft.

• Two adjustable 12W LED floodlights
• Equivalent to 2x75W BR30/halogen/wide floods
• Sensor with 180° detection pattern at up to 30 ft.

Product Information

Standard Information

• Brand: RAB
• Manufacturer Part Number: SMSBULLET2X12NA
• Country of Origin: Cambodia

Technical Specifications

• Watts: 24W
• Color Temp: 4000K (Neutral)
• Lumens: 2,528 lm
• Efficacy: 96.1 lm/W
• Color Accuracy: 84 CRI
• L70 Lifespan: 100,000 Hours
• Type: Constant Current
• 120V: 0.22A
• Input Watts: 26.3W
• UL Listed: Suitable for wet locations, wall mount only
• LEDs: Multi-chip, high-output, long-life LEDs
• Color Stability: LED color temperature is warrantied to Shift no more than 200K in color temperature over a 5-year period
• Color Uniformity: RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
• Lifespan: 100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
• Wattage Equivalency: 2x75W PAR30
• Thermal Management: Superior heat sinking with external Air-Flow fins
• Housing: Die-cast aluminum housing, lens frame and mounting plate
• Reflector: Semi-specular, vacuum-metalized polycarbonate
• Lens: Microprismatic diffusion lens for smooth and even light distribution
• Gaskets: High-temperature silicone gaskets
• Finish: Bronze
• Green Technology: Mercury and UV free. RoHS-compliant components.
• Mounting: Heavy-duty mounting arm with "O" ring seal and stainless steel screws
• Switching Capacity: 500W of LED BULLET12 floods
• Voltage: 120VAC, 60Hz
• Sensor Power Consumption (when idle): 1 Watt
• Time Adjustment: 5 seconds to 15 minutes
• Sensor LED: Sensor indicator LED glows red day & night for "on guard" deterrence
• Surge Protection: Withstands up to 3000 Volts
• "No Hands" Auto Testing: Auto mode starts after 4 minutes of testing. No adjustment needed.
• Manual Override: Double flip wall switch logic prevents activation by momentary power outages. Override resets to auto at dawn. No extra wiring needed.
• RF Immunity: Circuits fully shielded for maximum radio frequency immunity
• Photoelectric Control: Deactivates lights during daylight. Fully adjustable for 24-hour operation or custom applications.
• Adjustments: Time, ambient light & sensitivity
• Brand: RAB Lighting
• Material: Bronze, Aluminum, Stainless Steel
• Style: Modern
• Light fixture form: Floodlight
• Room Type: Outdoor
• Specific Uses For Product: Wet locations or wall mount
• Indoor Outdoor Usage: Outdoor
• Power Source: Hardwired
• Other Special Features of the Product: Motion Sensor
• Control Method: Remote
• Light Source: LED
• Number of Light Sources: 2
• Light Color: cool white
• Lighting Method: LED
• Bulb Base: GU10
• Controller Type: Remote Control
• Switch Type: Motion Sensor
• Water Resistance Level: Water Resistant
• Connectivity Protocol: proprietary_wireless
• Brightness: 1914.00
• Efficiency: 105.33 LPW
• Mounting Type: Wall Mount
• Fixture Type: Non Removable
• Color Temperature: 4000 Kelvin
• Installation Type: Wall Mount
• Required Assembly: No
• Amperage: 0.22 Amp
• Applications: OUTDOOR
• Average Rated Life: 100,000 hr
• Color Rendering Index: 84
• Correlated Color Temp: 4,000 K
• Lamp Type: LED
• Lens Material: Microprismatic Diffusion
• Distribution: N/A
• Part Number: Smsbullet2X12Na
• Unit Count: 1.0
• MPN: SMSBULLET2X12NA
• Number in Pack: 1
• Features: Dusk-to-Dawn, Adjustable, Motion Sensor
• Bulb Wattage: 12 W
• Model Name: Smsbullet2X12Na
• Model: SMSBULLET2X12NA
• Power Consumption: 24 W
• Smart Home Protocol: RAB Lighting
• Country of Origin: China
• Volts: 120V
• HID Equivalent: 150W
• Lumens Per Watt: 96
• CRI: 84
• Dimmable: No
• Length (M.O.L.) Inches: 14.5
• Height (Inches): 6
• Width (Inches): N/A
• Wet/Damp Rated: Wet
• Maximum Temp: N/A
• Rated Hours: 100,000
