Rab SLIM12W Slim® 12W

Product Description

The RAB SLIM12W Slim® is a full cutoff, fully shielded LED wall pack that can be used as a downlight or uplight. It has contractor-friendly features for easy installation and a 100,000-hour LED life. This wall pack has an ingress protection rating of IP66 for dust and water and is ADA compliant.

• Full cutoff, fully shielded LED wall pack
• Can be used as a downlight or uplight
• Contractor friendly features for easy installation

Product Highlights

This LED wall pack offers versatile mounting options and long-lasting performance, suitable for wet locations and designed for energy efficiency.

Product Information

Standard Information

• Brand: RAB
• Manufacturer Part Number: SLIM12W

Technical Specifications

• Watts: 12W
• Color Temp: 3000K (Warm)
• Lumens: 2,006 lm
• Efficacy: 133.7
• Color Accuracy: 72 CRI
• L70 Lifespan: 100,000 Hours
• Type: Constant Current
• 120V: 0.13A
• 208V: 0.08A
• 240V: 0.07A
• 277V: 0.06A
• Input Watts: 15W
• UL Listed: Suitable for wet locations. Suitable for mounting within 4 ft (1.2m) of the ground.
• IP Rating: Ingress protection rating of IP66 for dust and water
• ADA Compliant: SLIM™ is ADA Compliant
• IESNA LM-79 & LM-80 Testing: RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNAlm-79 andlm-80.
• Dark Sky Conformance: Dark Sky Approved in 3000K. Conforms to (allows for conformance to) the IDA's fully shielding requirement, emitting no light above 90 degrees (with the exclusion of incidental light reflecting from fixture housing, mounts, and pole).
• DLC Listed: This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
• DLC Product Code: P0000171L
• Driver: Constant Current, Class 2, 120-277V, 50-60Hz, 120V: 0.13A, 208V: 0.08A, 240V: 0.07A, 277V: 0.06A
• Dimming Driver: Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
• THD: 5.19% at 120V, 8.55% at 277V
• Power Factor: 99.4% at 120V, 94% at 277V
• LEDs: Long-life, high-efficacy, surface-mount LEDs
• Color Consistency: 3-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
• Color Stability: LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period
• Color Uniformity: RAB's range of Correlated Color Temperature follows the guidelines for the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
• Lifespan: 100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
• Wattage Equivalency: Equivalent to 70W Metal Halide
• Cold Weather Starting: The minimum starting temperature is -40°F (-40°C)
• Maximum Ambient Temperature: Suitable for use in up to 104°F (40°C)
• Housing: Precision die-cast aluminum housing
• Lens: Tempered glass lens
• Reflector: Specular thermoplastic
• Gaskets: High-temperature silicone
• Finish: Formulated for high durability and long-lasting color
• Green Technology: Mercury and UV free. RoHS-compliant components.
• Mounting: Heavy-duty mounting bracket with hinged housing for easy installation
• Recommended Mounting Height: Up to 8 ft
• HID Replacement Range: Replaces 70W Metal Halide
• BUG Rating: B1 U0 G0
• Brand: RAB Lighting
• Material: Plastic
• Style: Modern
• Light fixture form: Wall
• Room Type: Bathroom
• Specific Uses For Product: Porch
• Indoor/Outdoor Usage: Indoor
• Power Source: Corded Electric
• Installation Type: Wall Mount
• Control Method: Remote
• Light Source Type: corded electric
• Finish Type: Painted
• Shade Material: Plastic
• Number of Light Sources: 1
• Voltage: 120 Volts
• Light Color: warm white, natural white, cool white
• Lighting Method: LED
• Bulb Base: E26
• Controller Type: Remote Control
• Unit Count: 1.0 Count
• Water Resistance Level: Waterproof
• Brightness: 1350 lumen
• Efficiency: High
• Shade Color: White
• Fixture Type: Non Removable
• Assembly Required: No
• Manufacturer: RAB Lighting
• Light Output Maximum: 1350 Lumens
• Model Name: RAB Lighting SLIM12NW
• Part Number: SLIM12NW
• Item model number: SLIM12NW
• Finish types: Painted
• Plug Format: A- US style
