Rab Lighting X34LT Field-adjustable floodlight 90W/80W/70W (Trunnion mount)

Brand: RAB LIGHTING
SKU: X34LT
Availability: In Stock

Ships same day if ordered by 12 pm
$244.71
$244.71
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The RAB Lighting X34LT is a field-adjustable LED floodlight with selectable power (90W/80W/70W) and selectable color temperatures (3000K/4000K/5000K). It delivers 10,313–14,040 lumens with 136.8–163.6 lm/W efficacy, 83–86 CRI, integrated on/off photocell, and 0-10V dimming. The fixture is die-cast aluminum with tempered glass, mounts via a trunnion with -90° to +90° tilt, is IP65 rated, and has a 100,000-hour L70 life rating.

  • Field-selectable wattage (90W/80W/70W) and color temperature (3000K/4000K/5000K); factory default 90W/4000K
  • Integrated on/off photocell, 0-10V dimming to 10%, and wide 7H x 7V NEMA distribution
  • Die-cast aluminum housing, tempered glass lens, IP65 wet-location rating, -40°F starting to 104°F maximum ambient

Product Highlights

Field-adjustable wattage and CCT; integrated photocell and 0-10V dimming; IP65 rated with 100,000-hour L70 life

Product Information

Standard Information

  • Brand: RAB LIGHTING
  • Manufacturer Part Number: X34LT
  • Country of Origin: Cambodia
Technical Specifications
Brand
RAB Lighting
MPN
X34LT
Model
X34LT
Product Name
Field-Adjustable Floodlight
Light Source
LED
Wattage
Field adjustable: 90W / 80W / 70W (factory default 90W)
Power Consumption
68.1 - 93.6 W
Lumens
10,313 - 14,040 lm
Efficacy
136.8 - 163.6 lm/W
CRI
83 - 86
L70 Lifespan
100,000 Hours
Metal Halide Equivalent
350 - 400 W
Input Voltage
120 - 277 V
Frequency
50/60 Hz
Input Current (A)
90W: 0.78A/0.44A/0.38A/0.35A (120V/208V/240V/277V); 80W: 0.69A/0.40A/0.34A/0.31A; 70W: 0.59A/0.34A/0.30A/0.27A
Dimming
0-10V dimming (dimmable to 10%)
Photocell
Integrated on/off photocell
Beam Spread
7H x 7V (NEMA)
Mounting Type
Trunnion mount
Tilt Range
-90° to +90° (30° increments)
Housing Material
Die-cast aluminum
Lens Material
Tempered glass
Reflector
Polyethylene terephthalate (PET)
IP Rating
IP65
Location Rating
Wet locations
Cold Weather Starting
-40°F (-40°C)
Operating Temperature
-40°F to 104°F (maximum ambient 104°F / 40°C)
Effective Projected Area (EPA)
0.9
Finish
Bronze
Dimensions
10.5 in L x 3.25 in W x 10.38 in H
Listings/Certifications
UL Listed; DLC Listed (DLC Premium); IESNA LM-79 & LM-80 tested; RoHS; Trade Agreements Act Compliant
DLC ID
S-EZPO0W
