Rab BRISK17FA20 Field Adjustable LED Wallpack 20W 3000K/4000K/5000K

Product Description

The RAB BRISK17FA20 field adjustable LED wallpack operates from 120 to 277 V and consumes 20 W. This LED wall pack has a color rendering index (CRI) of 80 and a selectable color temperature of 3000K/4000K/5000K. It delivers between 2600 to 2921 to 2703 lumens and is suitable for wet locations.

• Heavy duty, die-cast junction box with (4) conduit entries (one top, two side, one back)
• Formulated for high durability and long-lasting color
• Mercury and UV free

Product Highlights

This RAB LED wallpack is equivalent to 100 Watt metal halide and features a long life, high-efficiency, surface-mount LED.

Product Information

Standard Information

• Brand: RAB
• Manufacturer Part Number: BRISK17FA20

Technical Specifications

• Color Temperature: 3000K/4000K/5000K
• Fixture Wattage: 20 W
• Voltage Rating: 120 to 277 V
• Lumens: 2600/2921/2703 Lumens
• Color Rendering Index (CRI): 80 CRI
• Lamp Type: LED
• Vendor SKU: BRISK17FA20
• Manufacturer: RAB Lighting
• Brand: RAB
• Includes: 120 - 277 Volt Photocell
• Mounting: Heavy-Duty Junction Box
• Lamp Wattage: 20 Watt
• Item Name: LED Wall Pack
• Frequency Rating: 50/60 Hz
• Temperature Rating: 45 deg C Ambient, -30 deg C Cold Starting
• Finish: Bronze
• Environmental Conditions: Wet Location
• Dimmable: Yes
• Construction: Precision Die Cast Aluminum, Heavy-Duty Die Cast Junction Box
• Style: Traditional
• Standards: UL Listed, DLC Listed, IESNA LM-79 And LM-80 Tested, IP65 Rated, RoHS Compliant
• Driver Type: 19.3/19.9/19.7 Watt, 0.2 Amp at 120 Volt, 0.1 Amp at 208 Volt, 0.08 Amp 240 Volt, 0.07 Amp at 277 Volt, Class 2, Constant Current, 0 - 10 Volt Dimming
• Average Life: 100000 Hour
• Collection: Brisk®
• Manufacturer Name: Rab
• GTIN: 00192552004367
• UPC: 19255200436
• Energy Star Flag: No
• Manufacturer Part Number: BRISK17FA20
• UNSPSC: 39111503
• 120V: 0.20A
• 208V: 0.10A
• 240V: 0.08A
• 277V: 0.07A
• DLC Listed: PLLLMBSHJ6UX
• DLC Type: DLC Premium
• DLC Version: 5.1
• Driver: Constant Current
• Efficacy: 134 LPW
• Rated Hours: 10,000 Hours
• Min Operating Temp: -40 Degrees F
• CRI: 80+
• Special Features: CCT Selectable, Photocell Installed, Wet Location Rated
• Ambient Temperature: 113 degrees F
• Color Accuracy: 80 CRI
• Correlated Color Temp: 3000 K
• Minimum Starting Temp: -40 degrees C
