Rab A17XFU150 A17 Area Light 150W (1 Lamp)

Brand: RAB
SKU: A17XFU150
Availability: In Stock

Ships same day if ordered by 12 pm
$615.40
$615.40
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

Rab A17XFU150 is an A17 area LED light with one integrated 150W adjustable LED lamp and field-selectable power (70W/100W/150W). It is rated for 120, 208, 240 and 277 V and provides 11,168 lumens. The fixture has a die-cast aluminum housing, polycarbonate lens, IP65 enclosure rating, 0-10V dimming and an integrated NEMA 7-pin receptacle for smart control upgrades.

  • Field-adjustable wattage 70W/100W/150W with 0-10V dimming and included dimming driver
  • Integrated NEMA 7-pin receptacle for smart control upgrades and reversible house-side shields
  • Die-cast aluminum housing with polycarbonate lens, IP65 enclosure, universal pole adapter included

Product Highlights

150W field-adjustable LED area light, 11,168 lumens, IP65, 100,000-hour L70, 120/208/240/277 V

Product Information

Standard Information

  • Brand: RAB
  • Manufacturer Part Number: A17XFU150
  • Country of Origin: China
Technical Specifications
Brand
Rab
MPN
A17XFU150
Series
A17
Lamp Type
LED
Wattage
150 W (field-selectable 70 W / 100 W / 150 W)
Input Voltage
120, 208, 240, 277 V
Input Current (A)
Approx. 1.25 A (120V), 0.72 A (208V), 0.63 A (240V), 0.54 A (277V) — at 150W setting
Lumens
11,168 lm (typical at specified lumen output)
Lumens per Watt
Approximately 74 lm/W at 150W (note: 11,168 lm / 150 W = ~74 lm/W). Field-selectable settings will change lm/W
Color Temperature
2700 K (product states field/color adjustable - confirm SKU for other CCTs)
Color Rendering Index (CRI)
71 to 73
Dimming
0-10V dimming
Photocell
3-pin twistlock photocell and shorting cap (included in some SKUs)
Lens Type
Polycarbonate
Housing Material
Die-cast aluminum
Housing Finish
Bronze
Mounting Type
Universal Pole Adapter; round pole adaptor plate included
Number of Lamps
1 (integrated LED)
Dimensions
6-5/16 in H x 11-1/4 in W x 28-3/8 in D
Weight
13.2 lb (manufacturer spec listed)
Average Life / L70
100,000 hrs
Enclosure Rating
IP65
Distribution Type
Type III medium-narrow distribution
Includes
Round pole adaptor plate and dimming driver (3-pin twistlock photocell and shorting cap included in some SKUs)
Standards & Approvals
UL Listed; BAA Compliant; RoHS-Compliant; DLC Listed; IESNA LM-79 and LM-80; ANSI C78.377-2017 / C136.31 / C136.41
GTIN / UPC
00192552003872 / 192552003872
Features
Integrated NEMA 7-pin receptacle for smart control upgrades; reversible house-side shields; 70W/100W/150W power adjustable; color adjustable; 0-10V dimmable
