Quickfitting LF811PBYR transition coupling 1/2 in. replacement LF811PBYR

Product Description

The QUICKFITTING LF811PBYR transition coupling quickly transitions from polybutylene to copper, PEX, and CPVC. This fitting provides a reusable, durable, and secure connection for hot or cold water lines. It features a patented design that ensures superior sealing and is backed by a 75-year warranty.

• Quickly transition from polybutylene to copper, PEX and CPVC
• Reusable, durable, secure fitting for hot or cold water lines
• Superior sealing with patented design backed by 75-year warranty

Product Highlights

This coupling offers fast, trouble-free installation and is suitable for potable water applications. No special tools are required.

Product Information

Standard Information

• Brand: QUICKFITTING
• Manufacturer Part Number: LF811PBYR
• Country of Origin: China

Technical Specifications

• Double Fitting Size: 1/2" x 1/2"
• Pack Size: 1
• MFR #: LF811PBYR
• Zoro #: G613813926
• UPC #: 845526016681
• Country of Origin: China
• Tube Size: 1/2 in
• Pipe Size - Pipe Fitting: 1/2 in
• Pipe Size (Fittings): 1/2 in
• Pipe Size: 1/2 in
• Tube Outside Dia.: 1/2 in
• Length: 1-29/32 in
• Item: Transition Coupling
• Tube Fitting Material: Lead Free Brass
• Basic Fitting Shape: Coupling
• Specific Fitting Shape: Straight Adapter
• Fitting Connection Type: Push-Fit
• Max. Pressure: 200 psi
• Body Material: Brass
• Connection Type: Push-to-Connect x Push-to-Connect
• Special Features: Removable; Lead-Free; Superior sealing with patented design backed by 75-year warranty; Connects Copper, PEX and CPVC piping in plumbing and heating applications with no open flames or sealants needed
• Max. Temp.: 200 Degrees F
• Temp. Range: 33 Degrees to 200 Degrees F
• Gasket Material: EPDM
• Basic Pipe Fitting Material: Metal
• Basic Pipe Fitting Shape: Coupling
• Standards: ASSE 1061-2015; NSF/ANSI/CAN 61-2019; NSF/ANSI/CAN 372-2020
• Application: Potable Water
• Pipe Fitting Connection Type: Push-to-Connect
• End Connection Type: Push-to-Connect
• For Tubing O.D. 1: 1/2 in
• Thread Size: 1/2 inch
• Size: 1/2 inch x 1/2 inch FNPT
• Fitting Type: Push-To-Connect
• Minimum Operating Temperature: 200-degrees Fahrenheit
• Minimum Operating Pressure: 200 psi
• Fitting Shape: Straight Coupling
• Weight (lb): 0.10
• Size (W x H x D): 4.00 00d76.00 00d712.00
• Fitting Size 1: 1/2 In.
• Fitting Size 2: 1/2 In. CTS
• Connection Type 1: Push
• Connection Type 2: Push
• Material: Brass
• Pressure Rating (psi): 200
• Maximum Working Temperature (F): 200
• For Use With: Copper, CPVC, PEX and Polybutylene
• Connectivity: Push
• Unit of Measurement: Each
• Compatible Pipe Material: CPVC, Copper, PEX, Polybutylene
• Maximum Working Pressure: 200 psi
• Maximum Working Temperature: 200° F
