Qmark M602W Snap Action Thermostat 120-277V

Product Description

The Qmark M602W is a double pole snap action thermostat. This thermostat operates at line voltage and supports multiple voltage levels including 120 volts, 208 volts, 240 volts, and 277 volts. It is designed for use with various electric heating systems, such as baseboard heaters. The M602W features a large adjustment knob for easy temperature setting. Its design includes a positive off setting for safety when not in use.

• Compatible with different electric heating products
• Snap action technology for quick response
• Temperature range from 45°F to 75°F

Product Highlights

This unit is ideal for controlling electric heating sources.

Product Information

Standard Information

• Brand: Qmark
• Product Type: Thermostat

Technical Specifications

• MPN: M602W
• Voltage Compatibility: 120V, 208V, 240V, 277V
• Amperage Rating: 22 amps max at 120V, 208V, 240V; 18 amps max at 277V
• Wiring Configuration: Double Pole, 2 Black and 2 Red wires
• Differential: +/- 4°F
• Size: 5 inch depth, 3.25 inch width, 2.88 inch height
