Proto J5418H Skt 1/2 Dr 9/16 6 Pt

Product Description

The PROTO J5418H is a Skt 1/2 Dr 9/16 6 Pt. Proto sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials. The TorquePlus design allows for quick and easy socket engagement to the fastener flats, not the corners. It is constructed from forged alloy steel with a nickel chrome finish.

• The TorquePlus internal design minimizes fastener rounding and helps extend fastener life.
• Ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
• High performance drive configuration allows for quick and easy socket engagement.

Product Highlights

The PROTO socket is designed for use with a 1/2" drive and features a 9/16" opening size with 6 points.

Product Information

Standard Information

• Brand: PROTO
• Manufacturer Part Number: J5418H
• Country of Origin: US

Technical Specifications

• MPN: J5418H
• Brand: PROTO
• Category 1: HAND TOOLS
• Category 2: SOCKETS RATCHETS ADAPTORS & EXTENSIONS
• Height: 1.55
• Length: 0.8
• Width: 0.8
• Drive Size [Nom]: 1/2 in
• Drive Type: Square
• Finish: Nickel Chrome
• Head Width [Nom]: 13/16 in (opening side); 55/64 in (drive side)
• Locking Type: Ball
• Material: Forged Alloy Steel
• Measuring System: Inch
• No. of Points: 6
• Opening Size [Nom]: 9/16 in
• Overall Length [Nom]: 1 1/2 in
• Nut End Outside Diameter [Imperial]: 13/16 in
• Drive End Outside Diameter [Imperial]: 55/64 in
• Nut Depth [Imperial]: 23/64 in
• Bolt Clearance Depth [Imperial]: 51/64 in
• Overall Length [Imperial]: 1-1/2 in
• Product Weight [Imperial]: 0.13 lbs
• Socket End Width: 13/16 in
• Socket Type: 6 Point
• Socket Size: 9/16 in
• Impact Rated: No
• Socket Depth: Standard
• Drive Size: 1/2 in
• Measurement Type: SAE
• Standards: ASME B107.110-2012, SAE AS4984A
• Tether Ready: Not Tether Capable
• UNSPSC: 27111704
• Socket Points: 6 Points
• Regular Or Impact: Regular
• SAE or Metric: SAE
• Overall Length: 1.5 in
• VMRS Code: 053006195
