Rheem 51-23053-11 Protech Condenser Motor 1/3 HP 208-230V 1075 RPM

Product Description

The Rheem 51-23053-11 Protech Condenser Motor offers reliable and efficient performance for various industrial applications. Designed with 1/3 horsepower and a voltage range of 208 to 230, this motor operates at a single speed of 1075 RPM, ensuring consistent performance.

• 1/3 horsepower motor
• Voltage range: 208-230 V
• Single-speed operation at 1075 RPM

Product Highlights

The motor is suitable for condenser fans, pumps, and blowers. Its compact design with a rolled steel frame and aluminum flange ensures durability and corrosion resistance.

Product Information

Standard Information

• Brand: Rheem
• MPN: 51-23053-11

Technical Specifications

• Horse Power: 1/3 HP
• Voltage Rating: 208-230V
• Phase: 1-Phase
• RPM: 1075 rpm
• Shaft Diameter: 1/2 inch
• Shaft Length: 4-1/4 inch
• Mounting: Shell-Band, Shell-Screw, Thru-Bolt
• Overall Length: 8-1/4 inch
• Frame: NEMA 48
• Amperage Rating: 1.75A
• Bearing Type: Ball
• Rotation: Reversible
