Johnson Controls VA9208-GGA-2 Ball Valve 24V S/R 0-10VDC

Product Description

The Johnson Controls VA9208-GGA-2 Ball Valve is a reliable and efficient valve actuator designed for HVAC applications. This proportional electric spring return valve actuator ensures precise positioning for Johnson Controls VG1000 Series ball valves.

• Direct mounting with a single screw
• Electronic stall detection
• Microprocessor-controlled brushless DC motor

Product Highlights

The VA9208-GGA-2 operates on a 24V power supply, responds to 0-10VDC signals, and is plenum-rated for use in air handling spaces. It is suitable for various applications such as air handling units and industrial automation systems.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: VA9208-GGA-2
• UPC:

Technical Specifications

• Voltage: 24V
• Signal Range: 0-10VDC
• Time Delay: 150 seconds
• Connection Type: Plenum-Rated Cable
• Torque: 70 lb-in
• Fail Safe Mode: Spring Return
• Weight: 4.08 lbs
• Dimensions: 11.55 x 6.55 x 3.9 inches
