Promax 100-03214 Corner Radius End Mill 1/2 in 4 Flute

Product Description

The PROMAX 100-03214 is a solid carbide corner radius end mill designed for precision milling operations in ferrous and non-ferrous materials. With a 1/2 inch cutting diameter and a corner radius range of 0.055 to 0.065 inches, this tool produces a controlled radius blend at the base of milled features, reducing stress concentrations and extending part life. The AlTiN coating provides thermal resistance for high-speed dry or near-dry machining. Four flutes and a 30-degree helix angle deliver an efficient balance of chip evacuation and surface finish quality. Overall length is 3 inches with a 1-1/4 inch length of cut.

This end mill is suited for CNC machining centers and manual mills used in tool rooms, production shops, and maintenance environments. The centercutting geometry allows plunge entry, making it practical for interpolated pockets and contour work. It is appropriate for applications requiring a consistent radius at step transitions, particularly in die and mold work, fixture machining, and general part production. A 1/2 inch shank diameter fits standard ER collet chucks and end mill holders common across most machining setups.

Key Features

• Solid carbide construction for rigidity and wear resistance in demanding cuts
• AlTiN coating rated for high-temperature, high-speed milling applications
• Corner radius of 0.055 to 0.065 inches reduces sharp edge stress at floor-wall intersections
• Centercutting design permits direct plunge entry and interpolated pocket milling
• 30-degree helix angle promotes smooth chip flow and improved surface finish
• Coarse pitch geometry suited for aggressive material removal rates

Compatibility

Designed as an OEM-style replacement or standard tooling option for CNC machining centers and manual mills accepting a 1/2 inch shank end mill holder or collet chuck.

Installation Notes

Installation should be performed by a qualified machinist or CNC setup technician. Ensure the machine spindle is fully stopped and the control is in an E-stop or safe state before inserting or removing the tool. Secure the shank fully within the holder to the recommended gauge line and torque the collet nut or set screw per the toolholder manufacturer specifications. Inspect the cutting edges for chips or coating damage before each use.
