Pro1 Iaq tp-p-605 thermostat 1 heat/1 cool

Product Description

The PRO1 IAQ TP-P-605 is a thermostat that features a large, easy-to-read backlit display and intuitive temperature set-point buttons. Configurable for electric or gas systems, it includes separate B and O terminals and adjustable heating and cooling swing. The thermostat offers room temperature calibration adjustments and a 5-minute compressor delay protection.

• Features a 2 sq. inch blue backlight display.
• Configurable for electric or gas systems.
• Offers separate heating and cooling swing adjustments.

Product Highlights

Programmable thermostat with a backlit display, configurable for various systems, and includes adjustable settings for optimal comfort.

Product Information

Standard Information

• Brand: PRO1 IAQ
• Manufacturer Part Number: TP-P-605
• Country of Origin: MEX

Technical Specifications

• SKU: TP-P-605
• 750mV Compatible: Yes
• Accuracy: 24 VAC
• Ambient Temperature Range: 41°F to 95°F (5°C to 35°C)
• Auto Changeover: No
• Backlit: Yes
• Batteries Included: Yes
• Battery Backup: Yes
• Built In Wi-Fi: No
• Change/Check Reminders: Yes
• Color: White
• Country of Origin: MEX
• Cubic Measurement: 0.018
• Daylight Savings Time Ready: No
• Differential Temperature: Plus or minus 2 degree
• Digital-Non Programmable: No
• Digital-Programmable: Yes
• Dimensional Weight: 5
• Display: Yes
• Display Options: LCD, Backlit
• Display Size: 2 sq. inch
• Displays Outdoor Temperature: No
• Dual Transformer Compatible: Yes
• Electrical Connection Type: 24 VAC
• Electrical Rating: 18-30 VAC, NEC Class II
• Energy Star Rated: No
• Fan Switching: Yes
• Heat Pump Compatible: Yes
• Hinged: No
• Humidification: No
• Indoor Remote Sensor: No
• Language: English
• Low Battery Indicator: Yes
• Manual: Yes
• Mounting Type: Drywall, stud, junction box
• Operating Temperature Range: 44°F to 90°F (6.6°C to 32.2°C)
• OPT Code: VIVET605
• Power Method: Battery; Hardwired
• Programmable Fan: No
• Prop 65: No
• Removable Interface: No
• Sensing Element: Yes
• System Switching: Yes
• Temperature Range: 44°F to 90°F (6.67°C to 32.22°C)
• Temperature Settings per Day: 4
• Terminal Designations: Rh, Rc, C, Y, W, G, O, B
• Touchscreen: No
• Vacation Mode: No
• Voltage: 24 VAC
• Weight: 0.75
• Works with Google Assistant: No
• Works with Rheem EcoNet: No
• Device Type: Programmable Thermostat
• Display Type: Black & White
• Connectivity: Powerline
• Heating Stages: 1
• Cooling Stages: 1
• Batteries: 2 AA Alkaline battery
• Battery Weight: 0.114 lb (51.7 grams)
• Dimensions (Inches): 4.7 x 4.4 x 1.1
• Battery Chemistry: Alkaline
• Battery Type: AA
• Programmable: Yes
• Control Type: Button Control
• Backlight: Yes
• Item Weight: 10 Pounds (4.54 kg)
• Brand Name: PRO1 IAQ
• Model Number: PROIAQ-T605-2_CASE
• Manufacturer: PRO1 IAQ
• Manufacturer Part Number: PROIAQ-T605-2_CASE
• ASIN: B07H5MRFWG
• Brand: PRO1 IAQ
• Special Feature: Programmable
• Date First Available: 2023-04-28 01:28:44
