Pro-source PRO17816201PL Pleated Air Filter 16x20x1 Washable

Product Description

The PRO-SOURCE PRO17816201PL is a washable pleated air filter designed for large particle removal in forced-air HVAC systems. Built with a steel media and steel frame construction, this filter handles airflow up to 1,100 CFM at a maximum face velocity of 300 feet per minute. Its permanent, washable design makes it a reusable alternative to disposable media filters. Nominal dimensions are 16 x 20 x 1 inches, with actual dimensions of 15-1/2 x 19-1/2 x 3/4 inches. HVAC technicians and facilities maintenance professionals install this filter in residential and light commercial air handling units and furnaces.

This filter is suited for applications where large airborne particles such as dust, lint, and debris are the primary concern. The steel frame construction allows it to withstand temperatures up to 250 degrees F, making it appropriate for use in higher-temperature air handler environments. Its washable, permanent design supports ongoing maintenance programs where filter replacement costs need to be minimized. It is packaged and sold individually.

Key Features

• Washable and reusable permanent filter construction
• Steel media and steel frame rated for up to 250 degrees F
• Maximum airflow of 1,100 CFM at 300 feet per minute face velocity
• Final resistance of 1 inch w.g. at rated FPM
• Nominal size: 16 x 20 x 1 inches; Actual size: 15-1/2 x 19-1/2 x 3/4 inches
• Integrated frame design for secure, stable fitment in filter tracks

Compatibility

Designed for large particle removal applications in forced-air HVAC systems that accept a 16 x 20 x 1 inch nominal filter size.

Installation Notes

Installation should be performed by a qualified HVAC technician or trained maintenance professional. Always shut down the air handling unit or furnace and disconnect power before removing or installing the filter. Verify that the filter track and housing accommodate the actual dimensions of 15-1/2 x 19-1/2 x 3/4 inches before installation. When cleaning this washable filter, allow it to dry completely before reinstalling to prevent moisture from entering the air stream.
