Pro-source PRO10454 Pleated Air Filter 14x25x2 Merv 10

Product Description

The PRO-SOURCE PRO10454 is a wire-backed pleated air filter rated MERV 10 with 55% particle capture efficiency. It measures 14 x 25 x 2 inches nominal (13.5 x 24.5 x 1.75 inches actual) and uses a synthetic filter media supported by a wire backing and enclosed in a paperboard frame. Rated for airflow up to 1,200 CFM at a maximum face velocity of 500 feet per minute (FPM), this filter is suited for residential and light commercial HVAC systems where mid-range filtration is required. It meets ASHRAE 52.2-2012 and is UL 900 listed. Installation is straightforward for HVAC technicians performing routine filter maintenance or seasonal changeouts.

This filter is designed for use with any forced-air heating or cooling unit that accepts a 14 x 25 x 2 inch filter. Typical applications include residential split systems, heat pumps, gas furnaces, and packaged rooftop units where a MERV 10 filter balances particulate capture with acceptable static pressure drop. The initial resistance is 0.24 inches water gauge at 500 FPM, with a final resistance of 1.0 inch water gauge, making it suitable for systems with standard blower capacity. It is rated for continuous service up to 200 degrees F.

Key Features

• MERV 10 rating with 55% particle capture efficiency per ASHRAE 52.2-2012
• Wire-backed pleated synthetic media for structural integrity at higher face velocities
• Paperboard frame with integrated construction for a secure, rigid fit
• Handles up to 1,200 CFM airflow at a maximum velocity of 500 FPM
• Low initial resistance of 0.24 inches water gauge at 500 FPM reduces blower strain
• Rated to 200 degrees F maximum operating temperature

Compatibility

Designed for use with any forced-air HVAC unit accepting a nominal 14 x 25 x 2 inch filter slot. Verify actual filter cabinet dimensions against the 13.5 x 24.5 x 1.75 inch actual size before installation.

Installation Notes

Installation is performed by HVAC technicians or qualified service personnel. Power down the air handler or furnace at the disconnect before removing the existing filter. Insert the new filter with the airflow arrow on the frame pointing toward the blower. Confirm the filter seats flush within the track with no bypass gaps around the frame edges.
