Pro-source CT138R 15 Split Ring Hanger 3/8 in 562 Lb

Product Description

The PRO-SOURCE CT138R 15 is a split ring hanger designed for suspending pipe runs from threaded rod in mechanical, plumbing, and HVAC piping systems. Constructed from malleable iron, this hanger provides a secure, two-piece split ring grip around the pipe, with the rod attachment point accepting a 3/8 inch threaded rod. It carries a rated load capacity of 562 pounds, making it suitable for medium-duty suspended piping applications. Licensed plumbers, pipefitters, and HVAC installers use split ring hangers when a rigid, rod-supported pipe suspension point is required in both new construction and retrofit work.

This hanger is used in residential and commercial mechanical rooms, utility spaces, and plenum areas where copper, steel, or other rigid pipe must be supported at regular intervals from structural members. It is a standard component in hydronic heating systems, chilled water lines, refrigerant piping supports, and domestic water distribution runs. The 3/8 inch rod size is a common specification in light to medium commercial and residential piping layouts, fitting standard threaded rod and hex nut hardware readily available on most job sites.

Key Features

• Malleable iron construction provides durability and resistance to deformation under sustained pipe load
• Split ring design allows installation around existing pipe without full disassembly of adjacent fittings
• Accepts 3/8 inch threaded rod for compatibility with standard hanger rod stock
• 562 pound load capacity rated for medium-duty suspended piping applications
• Single-unit packaging allows purchase of exact quantities needed for a job

Compatibility

Designed as an OEM-style replacement and standard-fit split ring hanger for suspended rigid pipe systems using 3/8 inch threaded rod support assemblies in residential and commercial mechanical installations.

Installation Notes

Installation is performed by licensed plumbers or pipefitters following applicable IPC and IFGC support spacing requirements for the pipe material and size in use. Shut off and depressurize the piping system before repositioning or replacing any hanger on a live line. Use properly sized threaded rod, nuts, and beam attachments rated for the total pipe weight including fluid and insulation. Do not exceed the rated load capacity of the hanger when calculating combined pipe, insulation, and fluid loads.
