Pro-source 6938002435PRO Stacking Solenoid Valve 4.5 Cv 24V

Product Description

The PRO-SOURCE 6938002435PRO is a pilot-actuated, 2-way, 2-position stacking solenoid valve designed for compressed air, hot water, and steam service. It operates on 24V DC and delivers a Cv rating of 4.5 with a maximum working pressure of 145 psi. The air pilot return mechanism resets the valve without an electrical signal, making it reliable in fail-safe and stacked manifold configurations. With both inlet and outlet sized at 3/8 inch and a maximum working temperature of 356 degrees F, this valve handles demanding industrial and process control applications. It is typically installed by industrial maintenance technicians, pipefitters, or pneumatic systems specialists working on fluid control assemblies.

This valve is suited for use in pneumatic and fluid control systems handling compressed air, hot water, or steam. Its 2-way, 2-position configuration makes it appropriate for on/off flow control in stacked manifold assemblies where space efficiency and modular valve arrangement are priorities. The 105.95 CFM flow capacity supports high-demand automation and process lines. Typical installation scenarios include industrial automation panels, process skids, and HVAC pneumatic control systems where multiple valves are ganged together on a common manifold.

Key Features

• 2-way, 2-position pilot-actuated design with air pilot return for fail-safe operation
• Cv rating of 4.5 supports high flow demand in stacked manifold setups
• Operates on 24V DC with a maximum working pressure of 145 psi
• Rated for media temperatures up to 356 degrees F — compatible with steam service
• 3/8 inch inlet and outlet ports for direct inline installation
• Flow capacity of 105.95 cubic feet per minute for compressed air service

Compatibility

Designed for use with compressed air, hot water, and steam systems. Fits stacking solenoid valve manifold assemblies requiring 2/2-way, pilot-actuated, air pilot return valves with 3/8 inch port sizing and 24V DC actuation.

Installation Notes

Installation should be performed by a qualified pipefitter, pneumatic systems technician, or industrial maintenance professional. Depressurize and de-energize the system fully before removing or installing the valve. Verify that line media, pressure, and temperature ratings are within the valve specifications before commissioning. Consult applicable local codes and system schematic documentation when integrating into a stacked manifold assembly.
