Pro-source 6912002430PRO Stacking Solenoid Valve 24VDC 4.5 Cv

Product Description

The PRO-SOURCE 6912002430PRO is a 2-way, 2-position stacking solenoid valve designed for pilot-actuated, air-pilot-return pneumatic circuit applications. It carries a Cv rating of 4.5 and operates on 24 volts DC, making it well-suited for integration into automated control manifolds where space-efficient valve stacking is required. The valve handles a maximum working pressure of 145 psi and a maximum working temperature of 194 degrees F. Fluid compatibility includes compressed air, light oil, and water. Industrial maintenance technicians and fluid-power specialists are the primary installers of this component in manufacturing, process control, and automated assembly systems.

This valve is intended for use in pneumatic and light hydraulic control systems where a compact, stackable form factor is needed. Its 1/2-inch inlet and 1/2-inch outlet ports accommodate standard compressed-air distribution lines. With a rated flow capacity of 96.16 cubic feet per minute, it supports moderate- to high-flow pneumatic actuator circuits. The air-pilot return design eliminates the need for a secondary electrical signal to return the valve to its normal position, which simplifies wiring in multi-valve manifold assemblies common in industrial automation environments.

Key Features

• 2-way, 2-position configuration for straightforward on/off flow control
• Pilot actuator with air-pilot return — no secondary solenoid required for return stroke
• 4.5 Cv rating supports flows up to 96.16 cubic feet per minute
• 24-volt DC coil voltage compatible with standard PLC output modules
• Rated to 145 psi maximum working pressure and 194 degrees F maximum working temperature
• Compatible with compressed air, light oil, and water media
• Stackable design for multi-valve manifold configurations

Compatibility

Designed for use with compressed air, light oil, and water systems requiring a 2-way, 2-position pilot-actuated stacking solenoid valve with 1/2-inch port connections and a 24-volt DC control signal.

Installation Notes

Installation should be performed by a qualified fluid-power technician or industrial maintenance specialist. De-energize the control circuit and relieve all system pressure before removing or installing any valve component. Verify that the supply voltage matches the 24-volt DC coil rating before energizing. Consult applicable pneumatic system design standards and local codes to confirm proper manifold assembly, port orientation, and sealing requirements.
