Pro-source 5530007522PRO Air Die Grinder 1/8 Inch Collet

Product Description

The PRO-SOURCE 5530007522PRO is a straight-handle air die grinder built for precision material removal, deburring, porting, and surface finishing in shop and field environments. Powered by compressed air at 90 psi and 1.5 CFM, it spins at 82000 RPM with 0.08 horsepower output. The 1/8 inch collet accepts a wide range of rotary burrs, mounted points, and small grinding wheels. Rear exhaust directs airflow away from the workpiece, keeping debris and chips out of the operator line of sight. Machinists, fabricators, HVAC technicians, and auto mechanics reach for this tool when tight tolerances and controlled grinding are required.

This die grinder is suited for use in fabrication shops, maintenance facilities, and mechanical service environments where high-speed rotary work is performed on metal, composite, or hard plastic surfaces. The straight handle configuration provides in-line control for detailed work in confined spaces such as pipe ends, weld joints, and port surfaces. It operates on a standard shop air supply, making it compatible with most existing compressed air infrastructure without special fittings or regulators beyond what is typically already in place.

Key Features

• 82000 RPM free speed for fast material removal and fine finishing
• 1/8 inch collet accepts standard rotary burrs and mounted points
• Rear exhaust directs air away from the work surface and operator
• Operates at 90 psi and 1.5 CFM air consumption
• Straight handle provides in-line grip for precise control in tight spaces
• Lightweight at 0.75 pounds for reduced fatigue during extended use

Compatibility

Designed for use with standard 1/8 inch shank rotary burrs, mounted points, and grinding accessories on any compressed air supply capable of delivering 90 psi at a minimum of 1.5 CFM.

Installation Notes

Connect to a clean, dry compressed air supply using an appropriately sized air line and fitting. Always verify the air supply pressure does not exceed the rated 90 psi before operation. Inspect the collet and collet nut for wear before installing any accessory, and ensure the mounted point or burr is fully seated and tightened before running the tool. Disconnect from the air supply before changing accessories or performing any maintenance.
