Pro-source 5230224511PRO 3-way Palm Button Air Valve

Product Description

The PRO-SOURCE 5230224511PRO is a 3-way, manually operated pneumatic air valve actuated by a palm button mechanism. It controls directional airflow in pneumatic circuits by shifting between two positions when the operator depresses the palm button. The valve carries a Cv rating of 0.976, indicating its flow capacity, and uses NPT threaded ports for connection to standard pneumatic plumbing. Weighing 0.48 pounds and standing 4.98 inches tall, it is a compact, mechanically operated unit suited for industrial and automation environments. Licensed pneumatic system technicians and maintenance mechanics are the typical installers.

This valve is used in pneumatic control applications where a manual, operator-initiated signal is required to shift air flow direction. It is well suited for workstation assembly lines, press controls, and other machinery where a deliberate palm-strike actuation prevents accidental triggering. The red color provides a visible indicator of the actuator location on a panel or fixture. Its 3-port, 2-position design makes it appropriate for single-acting cylinder control or similar directional control tasks in light industrial pneumatic systems.

Key Features

• Palm button actuator requires deliberate hand pressure, reducing the risk of accidental actuation
• 3-way, 2-position valve design suitable for single-acting cylinder or directional flow control
• Cv rating of 0.976 for consistent, measurable flow capacity
• NPT threaded ports for straightforward integration with standard pneumatic fittings
• Compact footprint: 4.98 inches tall, 1.38 inches wide, 1.02 inches in length
• Red actuator color provides quick visual identification on equipment panels

Compatibility

Designed as an OEM-style replacement or direct-install manual pneumatic valve for 3-way, 2-position NPT-ported pneumatic circuits in light to medium industrial applications.

Installation Notes

Installation should be performed by a qualified pneumatic or mechanical technician. Before servicing or replacing this valve, depressurize and lock out the pneumatic system in accordance with applicable OSHA lockout/tagout procedures. NPT threads should be sealed with appropriate thread sealant tape or compound rated for pneumatic service. Verify port orientation and flow path match the intended circuit diagram before returning the system to operation.
